A Menu Structure FLUXUS WD100, WD200
UMFLUXUS_F5WDV1-1EN, 2016-04-08 93
selection of the sample mode
• sample: storing and online transmission of the displayed measured value
• average: storing and online transmission of the average of all measured val-
ues of a storage interval
x
setting of the storing behavior of the totalizers
• one: the value of the totalizer that is currently displayed will be stored
• both: one value for each flow direction will be stored
x
activation of the storing of the signal amplitude
The value will only be stored if the data logger is activated.
x
activation of the storing of the sound speed of the fluid
The value will only be stored if the data logger is activated.
x
activation of the storing of diagnostic values x
SYSTEM settings\Miscellaneous
selection of the display for the setting of the contrast
setting of the contrast of the display
confirmation that a HotCode has to be entered
input of a HotCode
Instrum. Inform.
selection of the displays for information about the transmitter
display of the type, serial number and firmware version with the date (dd - day,
mm - month, yy - year)
x
Print Meas.Val.
selection of the displays for the transmission of stored measured values to a PC
error message that no measured values are stored
start of the transmission of measured values
This display will only be indicated if the data logger contains measured values
and the transmitter is connected to a PC via a serial cable.
INIT-
resistant
Storage mode
sample >AVERAGE<
Quantity Storage
one >BOTH<
SYSTEM settings↕
Miscellaneous
SETUP DISPLAY
CONTRAST
Please input a
HOTCODE: 000000
Special Funct. ↕
Instrum. Inform.
XXXX -XXXXXXXX
V x.xx dd.mm.yy
Special Funct. ↕
Print Meas.Val.
NO VALUES !
Print Meas.Val.
Send Header 01
................
To Next Page
