CI‐V
Connectanappropriate3.5mmCI‐Vpatchcablebetweentheradio'sREMOTEoutputandtheCI‐VInput
correspondingtothetunerPortused(AorB).Onlytwoconductorsareused(tipandsleeve).Three‐conductor
CI‐Vcablesmaybeused,andmodelsmayrequireacustom
cable.Pleaseconsulttheusermanualforyour
specificexciter.

CI‐VPatchCable
ConnecttheREMOTEoutputfromthetransceivertotheappropriateCI‐VInputAorCI‐VInputBconnectoron
yourTunerGeniusXL.

