Note:Ifyouwanttoviewtheimagefromyourcameraonamonitor,thecamera’s
digitalIP-videooutputmustbeconvertedtoanalogcomponent-videousingadecoder
unit.Suitablevideodecoderunitsareavailableseparately.
Documentillustrations
Y ourproductmaydifferslightlyfromthatshownintheillustrationsinthisdocument,
dependingonproductvariantanddateofmanufacture.
Allimagesareprovidedforillustrationpurposesonly.
Productdocumentation
Thefollowingdocumentationisapplicabletoyourproduct:
DescriptionPartnumber
M100/M200ThermalCameraInstallationandOperation
Instructions
InstallationandoperationofanM100–SeriesorM200–Series
thermalcameraandconnectiontoawidersystemofmarine
electronics.
71001
M100/M200–Seriessurfacemountingtemplate
MountingdiagramformountinganM100–SeriesorM200–Series
thermalcamera.
77001
M100/M200–Seriestop-downrisermountingtemplate
Mountingdiagramformountingthetop-downriserforan
M100–SeriesorM200–Seriesthermalcamera.
77003
M100/M200ThermalCameraVisualQuickStartGuide
Single-pageillustratedguidetohelpyougetup-and-running
withyourthermalcamera.
76001
LightHouse™2MFDOperationInstructions
DetailstheoperationoftheCameraapplicationforLightHouse™
2-compatiblemultifunctiondisplays.
81360
LightHouse™3MFDAdvancedoperationInstructions
DetailstheoperationoftheCameraapplicationforLightHouse™
3-compatiblemultifunctiondisplays.
81370
Documentandproductinformation
17
