3.1Installationchecklist
Installationincludesthefollowingactivities:
InstallationT ask
1
Planyoursystem.
2
Obtainallrequiredequipmentandtools.
3
Siteallequipment.
4
Routeallcables.
5
Drillcableandmountingholes.
6
Makeallconnectionsintoequipment.
7
Secureallequipmentinplace.
8
Poweronandtestthesystem.
Schematicdiagram
Aschematicdiagramisanessentialpartofplanninganyinstallation.Itisalsouseful
foranyfutureadditionsormaintenanceofthesystem.Thediagramshouldinclude:
•Locationofallcomponents.
•Connectors,cabletypes,routesandlengths.
