•Notethecameraforwardmarkingsonthecamerabase,andmakesurethe
templateisorientedproperlyrelativetothebowofthevessel.Thisisaffectedby
whetherthecameraistobemountedball-uporball-down.
2.Installthe3xthreadedstudsintothebaseofthecamerawiththread-locking
compound.Ifrequired,youcanusestudsofadifferentlengthtosuityourinstallation.
3.Slidethesealoverthethreadedstuds,andpushitrmlyintoplaceonthecamera’s
base.
4.Connectthepowersupplycableandnetworkcabletothecamera,andthread
thecablesthroughthecentralholes.
Note:Theright-angledRayNetandpowercablessuppliedaresuitableforusewith
amountingsurfaceupto25.4mm(1in)thick.Athickersurfacewillrequirethe
useofstraight-connectorcables(availableseparately).
5.Placethecameraonthemountingsurfacesothethreadedstudsextendthrough
thedrilledholes.
6.Maketherequiredconnectionswiththefreeendsofthecables.
7.Slideaatwasher,andthenaspringwasher,ontoeachstud.
8.Securethecamerabodytothemountingsurfacewiththesuppliednuts,ensuring
thatthesealremainscorrectlypositionedonthecamera’sbase.
Tightenthenutstoatorqueof3.7Nm(2.7lb-ft).
Domecappednutsareprovidedforaneatersolutionwherethemountingis
exposedtoview.
Mountingthecamerawiththeoptionaltop-downriser(part
numberA80509)
Theoptionaltop-downriser(A80509)isusedwhenaccesstotheundersideofthe
mountingsurfaceisrestricted.Usetheinstructionsbelowtomountthecameraunit
usingtheoptionaltop-downriser(A80509).
1.Usingthetemplateprovided,markanddrilltheholesformountingtheriser.
•Notethecameraforwardmarkingonthetopsurfaceoftheriser.Y oumust
ensurethattheriserismountedsothatthecameraisorientedproperlyrelativeto
thebowofthevessel.
•Onlydrilltheoptionalcableroutingholeinthemountingsurfaceifyouintendto
routethecablesthroughthebaseoftheriser,ratherthanthroughthesideof
theriser.
54
