FLIR M100 Series User Manual

10.5RayNettoRayNetcablesandconnectors
DescriptionT ypicaluseQuantity
1
StandardRayNet
connectioncablewith
aRayNet(female)socket
onbothends.
SuitableforconnectingallRayNet
equipmentdirectlytoLightHouse
multifunctiondisplaysfeaturingaRayNet
connector.Canalsobeusedtoconnect
RayNetequipmentviaaRayNetnetwork
switch(e.g.HS5).
1
2
RayNetcablepuller(5
pack).
These“handles”securelyattachtothe
twist-lockonRayNetcables,enabling
youtopullthecablesthroughconduits
andotherobstacles.
5
3
RayNettoRayNet
right-anglecoupler/
adapter.
SuitableforconnectingRayNetcables
at90°(rightangle)todevices,for
installationswherespaceislimited.For
example,usethisadaptertoconnecta
RayNetcabletoamultifunctiondisplay
whenthereisnotenoughspacebehind
thedisplayfortheusualcablebend
radiusrequiredbyastandardRayNet
cable.ThisadapterfeaturesaRayNet
(female)socketatoneend,anda
RayNet(male)plugattheotherend.
1
4
Adaptercablewitha
RayNet(male)plugon
bothends.
Suitableforjoining(female)RayNet
cablestogetherforlongercableruns.
1
100
