FLIR M100 Series User Manual

10.4RayNettoRJ45adaptercables
DescriptionT ypicaluseQuantity
1
Adaptercablewitha
RayNet(female)socket
ononeend,anda
waterproof(female)
socketontheotherend
acceptingthefollowing
cableswithanRJ45
SeaT alk
hs
waterproof
locking(male)plug:
•A62245(1.5m).
•A62246(15m).
Atypicaluseforthisadaptercableisto
connectaDSM300sonarmoduletoa
LightHouseMFD,usingall-waterproof
cableconnections.Thisadaptercable
willalsoacceptthefollowingRJ45
SeaT alk
hs
cables,althoughtheRJ45
plugthatconnectsattheequipmentend
(e.g.DSM300)willNOTbewaterproof:
•E55049(1.5m).
•E55050(5m).
•E55051(10m).
•A62135(15m).
•E55052(20m).
1
2
Adaptercablewitha
RayNet(female)socket
ononeend,anda
waterproof(female)RJ45
socketontheotherend,
alongwithalocking
glandforawatertightt.
DirectlyconnectaRaymarineradar
scannerwithanRJ45SeaT alk
hs
(male)
cabletoaRayNetnetworkswitch(e.g.
HS5)orLightHouseMFD.
1
3
Adaptercablewitha
RayNet(male)plugon
oneend,andanRJ45
SeaT alk
hs
waterproof
(male)plugontheother
end.
ConnectalegacyG-SeriesGPM-400,
C-SeriesWidescreenorE-Series
WidescreenMFDtoaRaymarineradar
scannersuppliedwithaRayNetpower/
datacable.
1
