6.1Thermalcameraimage
Thethermalcameraprovidesavideoimagewhichisshownonyourprimaryvideo
display,webbrowser,orLightHouse™-poweredRaymarinemultifunctiondisplay(MFD).
TheIP-videofeedprovides:
•Thermalimage.
•Statusicons/systeminformation.
Y oushouldtaketimetofamiliarizeyourselfwiththethermalimage.Thiswillhelp
youtomakethemostofyoursystem:
•Considereveryobjectyouviewintermsofhowitwilllook“thermally”asopposedto
howitlookstoyoureye.Forexamplelookforchangescausedbytheheatingeffect
ofthesun.Theseareparticularlyevidentrightaftersunset.
•Experimentwithdifferentpalettesandscenepresets.
•Experimentbylookingforhotobjects(suchaspeople)comparedtothecolder
surroundings.
•Experimentwiththecamerafordaytimeviewing.Thecameracanprovideimproved
daytimeviewinginenvironmentswheretraditionalvideocameraperformancesuffers,
suchasinshadowsorbacklitscenes.
Thermalcamerastatusicons
Thethermalcameraimageincludesiconstoshowthecurrentstatusofthecamera.
IconDescription
Cameradirectionindicator.Showscameratiltandpan
(M200–Seriesonly).
Homeposition.Shownmomentarilyafteryouhave
conguredanewcamerahomeposition.
