FLIR M100 Series User Manual

ItemDescription
1
Laptop(orotherEthernet-connecteddevicerunningawebbrowser)
2
M100/M200–Seriescamera
3
RayNet-to-RJ45adaptercable
4
RayNet-to-RayNetcable
Single-camerasystemwithwebbrowserandanoptionalJCU
Note:Powerconnectionsarenotshowninthisillustration.Thecameraandtheother
devicesshownrequiretheirowndedicatedpowerconnection.
ItemDescription
1
Ethernetnetworkswitch
2
M100/M200–Seriescamera
3
Joystickcontrolunit(JCU-3)
4
Laptop(orotherEthernet-connecteddevicerunningawebbrowser)
5
RayNet-to-RayNetcable
6
RayNet-to-RJ45adaptercable
7
RJ45-to-RJ45Ethernetcable
Single-camerasystemwithanalogvideomonitorandJCU
Forthissystem,adevicerunningawebbrowserisnotrequired.Thecamera’sIPvideo
feedisroutedthroughanEthernetnetworkswitchtoanIPvideodecoder(available
separately),andontoananalogvideomonitor.CameracontrolisprovidedbyaJCU.
Cablesandconnections45
