Note:
•Ifitisnotpossibletoroutethecameracablesthroughthemountingsurface,cuta
holeinthesideoftheriser,androutethecablesthroughtherisersidewall.Y ou
mayneedtoloopthecablesaroundwithintheriserbase,sothattheycanbe
passedthroughtheholeyouhavecutinthesideoftheriser.
•Ifroutingthecameracablesthroughtherisersidewall,andthecameraismounted
ball-up,doNOTsealtheriserbasewitheitherthesuppliedgasket,orsealant.
Sealingmayresultinwaterpoolinginsidetheriser.
•Ifroutingthecameracablesthroughtherisersidewall,andthecameraismounted
ball-down,doNOTsealtheconnectionbetweenthecamerabaseandthetop
surfaceoftheriserwiththesuppliedgasket.Sealingmayresultinwaterpooling
insidetheriser.
