Technical data26
Image presentation
Viewfinder Built-in 800 × 480 pixels
Automatic image adjustment
Continuous, histogram based
Automatic image adjustment, type Standard or histogram based on the image
content
Manual image adjustment Linear based, possible to adjust level/span/max./
min.
Image presentation modes
Image modes
Thermal, thermal MSX, picture in picture, digital
camera
Infrared image Full color infrared image
Visual image Full color visual image
Multi Spectral Dynamic Imaging (MSX)
Thermal image with enhanced detail presentation
Picture in Picture Resizable and movable infrared area on the visual
Gallery
• Review thumbnail/full image on the camera
• Edit measurements/palettes/image modes on
the camera
Measurement
Object temperature range
Accuracy
–40 to +150°C (–40 to +302°F) –40 to +5°C (–40 to +41°F) ±2°C (±3.6°F)
+5 to +100°C (+41 to +212°F) ±1°C (±1.8°F)
+100 to +150°C (+212 to +302°
F)
±1%
0 to +650°C (+32 to +1202°F) 0 to +100°C (+32 to +212°F) ±2°C (±3.6°F)
+100 to + 650°C (+212 to
+1202°F)
±2%
+300 to +2000°C (+572 to
+3632°F)
+300 to +2000°C (+572 to
+3632°F)
±2%
NOTE
For HSI use, above 30 Hz frame rate, the typical accuracy will be ±2.5°C (±4.5°F), or 2.5% of read-
ing @ 25°C (77°F).
Measurement analysis
Spotmeter
10
Area 5 + 5 areas (boxes and circles) with max./min./
average
Profile 1 line profile with max./min. temperature
Automatic hot/cold detection Auto hot or cold spotmeter markers within the
area and profile
Measurement presets
No measurements, Center spot, Hot spot, Cold
spot, User preset 1, User preset 2
User presets The user can select and combine measurements
from any number of spots/boxes/circles/profiles/
delta
Difference temperature Delta temperature between the measurement
functions and the reference temperature
Reference temperature Manually set using the difference temperature
#T559954; r. AP/42311/42335; en-US
122
