Achieving a good image15
Calibration is needed whenever the output image becomes spatially noisy. The output
can become spatially noisy when the ambient temperature changes (such as from day to
night operation, and vice versa).
The calibration is carried out automatically when needed. It is also possible to perform a
calibration manually.
While the calibration is in progress, the text Calibrating... is displayed.
15.7.2 Manual calibration
You may, for example, want to perform a manual calibration just before you start record-
ing a video sequence.
15.7.2.1 Procedure
Follow this procedure:
1. To perform a manual calibration, push and hold down the Image archive button
for more than 2 seconds.
Note You can also assign the function Calibrate to one of the programmable buttons.
Select
(Settings) > Programmable buttons .
15.8 Hiding all overlay
15.8.1 General
The camera overlay consists of overlay graphics and image overlay information. The
overlay graphics include items such as measurement tool symbols, result tables, and
status icons. The image overlay information, which you activate on the Settings menu,
provides additional information such as the date, emissivity, and atmospheric
temperature.
You can choose to hide all camera overlay by the press of a programmable button.
Image with camera overlay and image overlay
information.
Image with all overlay hidden.
15.8.2 Procedure
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
(Settings).
3. Push the joystick to display the Settings menu.
4. Select Programmable buttons and push the joystick.
5. Select one of the buttons and push the joystick.
6. Select Hide image overlay graphics and push the joystick. You have now assigned
this function to the selected programmable button.
#T559954; r. AP/42311/42335; en-US
