Changing settings
25
25.1 General
You can change a variety of settings in the camera. You do this on the Settings menu.
The Settings menu includes the following:
• Define user presets.
• Camera temperature range.
• Save options & storage.
• Programmable buttons.
• Device settings.
25.1.1 Define user presets
A user preset is a measurement tool, or a group of measurement tools, with predefined
characteristics. For more information, see section 17.3 Working with user presets, page
57.
• Define preset 1: This setting defines user preset 1.
• Define preset 2: This setting defines user preset 2.
25.1.2 Camera temperature range
For accurate temperature measurements, you must change the Camera temperature
range setting to suit the expected temperature of the object you are inspecting.
Available temperature range options are dependent on the camera model. The unit (℃
or ℉) depends on the temperature unit setting, see section 25.1.5 Device settings, page
81.
25.1.3 Save options & storage
• Save button half-press: This setting defines the function of the Save button. Available
options are:
◦ Autofocus: Pushing the Save button half-way down will autofocus the infrared
camera.
◦ None: Pushing the Save button half-way down will have no effect. With this setting,
you may want to assign the autofocus function to one of the programmable buttons.
• Preview image before saving: This setting defines if a preview image will be displayed
before the image is saved.
• Add annotation after saving: This setting defines if an annotation tool will be displayed
when the image has been saved. Available options are:
◦ Save: No annotation tool will be displayed.
◦ Save & add note: The note annotation tool will be displayed.
◦ Save & add table: The table annotation tool will be displayed. This setting also al-
lows you to define the type of table. Available options are the default table
#T559954; r. AP/42311/42335; en-US
79
