FLIR T1020 User Manual

Saving and working with images
14
5. Select
(Information & reports) and push the joystick. This displays information
about the image.
6. Select Create report and push the joystick. The created report will be available in the
archive.
14.7 Deleting an image
14.7.1 General
You can delete an image file from the memory card.
Note Both images in the image file (thermal and visual) will be deleted.
14.7.2 Procedure
Follow this procedure:
1. Push the Image archive button
.
2. Move the joystick up/down or left/right to select the image you want to delete.
3. Push the joystick to display the image.
4. Push the joystick and select
(Delete) from the menu. This displays a dialog box.
5. Use the joystick to select Delete. Push the joystick to confirm.
14.8 Deleting multiple images
14.8.1 General
You can delete multiple image files from the memory card.
14.8.2 Procedure
Follow this procedure:
1. Push the Image archive button
.
2. Touch and hold one of the images you want to delete. This displays a context menu.
3. Touch all the other images you want to delete.
4. Use the joystick to select (Delete) and push the joystick. This displays a dialog
box.
5. Use the joystick to select Delete. Push the joystick to confirm.
#T559954; r. AP/42311/42335; en-US
47

FLIR T1020 Specifications

General

Resolution	1024 × 768 pixels
Detector Type	Uncooled microbolometer
Digital Camera	5 MP
Laser Pointer	Yes
Wi-Fi	Yes
Image Frequency	30 Hz
Detector Pitch	17 µm
Digital Zoom	1-8x continuous
Video Recording	Yes
Storage Media	SD card
Spectral Range	7.5 – 14 µm
Temperature Range	-40 °C to +2000 °C (-40 °F to +3632 °F)
Field of View	28° x 21°
Display	4.3 in LCD touchscreen, 800 × 480 pixels
Focus	Motorized and manual
Image Modes	Thermal, visual, MSX
Operating Temperature	-15 °C to +50 °C
Storage Temperature	-40 °C to +70 °C (-40 °F to +158 °F)
Connectivity	USB 2.0, HDMI
Image Storage	JPEG
Image Formats	JPEG
Thermal Sensitivity	<20 mK at 30°C
