Technical data26
26.20 Close-up lens 3× (51 µm) with case
P/N: T199065
Rev.: 30226
General description
The close-up lens is attached to the standard 28° IR lens and provides three times magnification. The
close-up lens is intended for R&D usage or development purposes. As an example, for studies of PCBs
and small electronic components.
Imaging and optical data
Field of view (FOV) 52° × 40° (66° diagonal)
Magnifying factor
3×
Working distance 97 mm (3.8 in.)
Depth of field 0.5 mm (0.02 in.)
Focal length 50 mm (2.0 in.)
Spatial resolution (IFOV)
51 µm
Lens identification No
F-number 1.15
Number of lenses 2 (2 asph)
Distortion 0.4%
Physical data
Weight 0.620 kg (1.37 lb.)
Size (L × D) 127.5 × 91 mm (5.02 × 3.58 in.)
Front lens diameter 76 mm (3.0 in.)
Shipping information
Packaging, type Cardboard box
List of contents
• Lens
• Lens case
• Front lens cap
• Rear lens cap
• Mounting instruction
Packaging, weight 0.96 kg (2.1 lb.)
Packaging, size 173 × 135 × 135 mm (6.81 × 5.31 × 5.31 in.)
EAN-13 7332558011003
UPC-12
845188011857
Country of origin Sweden
Compatible with the following products:
• 72501-0201; FLIR T1030sc 12°
• 72501-0202; FLIR T1030sc 28°
• 72501-0203; FLIR T1030sc 45°
• 72501-0401; FLIR T1050sc 12°
• 72501-0402; FLIR T1050sc 28°
• 72501-0403; FLIR T1050sc 45°
#T559954; r. AP/42311/42335; en-US
182

FLIR T1020 Specifications

General

Resolution	1024 × 768 pixels
Detector Type	Uncooled microbolometer
Digital Camera	5 MP
Laser Pointer	Yes
Wi-Fi	Yes
Image Frequency	30 Hz
Detector Pitch	17 µm
Digital Zoom	1-8x continuous
Video Recording	Yes
Storage Media	SD card
Spectral Range	7.5 – 14 µm
Temperature Range	-40 °C to +2000 °C (-40 °F to +3632 °F)
Field of View	28° x 21°
Display	4.3 in LCD touchscreen, 800 × 480 pixels
Focus	Motorized and manual
Image Modes	Thermal, visual, MSX
Operating Temperature	-15 °C to +50 °C
Storage Temperature	-40 °C to +70 °C (-40 °F to +158 °F)
Connectivity	USB 2.0, HDMI
Image Storage	JPEG
Image Formats	JPEG
Thermal Sensitivity	<20 mK at 30°C
