Technical data26
26.21 IR lens f=21.2 mm (45°) with case
P/N: T199066
Rev.: 30226
General description
The 45° has a field of view approximately two times that of the standard 28° lens. This wide angle lens
is suitable for cramped situations where the operator cannot step farther back from the object.
Imaging and optical data
Field of view (FOV) 45° × 34° (55.2° diagonal)
Minimum focus distance 0.2 m (0.66 ft.)
Focal length 21.2 mm (0.83 in.)
Spatial resolution (IFOV)
0.80 mrad
Lens identification Automatic
F-number 1.1
Number of lenses 4 (4 asph)
Distortion 1.71%
Physical data
Weight 0.754 kg (1.66 lb.)
Size (L × D) 96.9 × 91 mm (3.82 × 3.58 in.)
Front lens diameter 59 mm (2.3 in.)
Shipping information
Packaging, type
Cardboard box
List of contents
Lens
Lens case
Front lens cap
Rear lens cap
Mounting instruction
Packaging, weight 1.1 kg (2.4 lb.)
Packaging, size 173 × 135 × 135 mm (6.81 × 5.31 × 5.31 in.)
EAN-13 7332558010990
UPC-12
845188011840
Country of origin Sweden
Compatible with the following products
72501-0101; FLIR T1020 12°
72501-0102; FLIR T1020 28°
72501-0103; FLIR T1020 45°
72501-0104; FLIR T1020 28° and 12°
72501-0105; FLIR T1020 28° and 45°
72501-0106; FLIR T1020 28°, 12°, and 45°
72501-0201; FLIR T1030sc 12°
72501-0202; FLIR T1030sc 28°
72501-0203; FLIR T1030sc 45°
72501-0301; FLIR T1040 12°
72501-0302; FLIR T1040 28°
72501-0303; FLIR T1040 45°
72501-0401; FLIR T1050sc 12°
72501-0402; FLIR T1050sc 28°
72501-0403; FLIR T1050sc 45°
#T559954; r. AP/42311/42335; en-US
