FLIR T1020 User Manual

Camera parts
10
10.1 View from the right
10.1.1 Figure
10.1.2 Explanation
1. Knob to change the dioptric correction for the viewfinder.
2. Hand strap.
3. Digital zoom button.
4. Save button (push fully down).
Note The infrared camera can be configured to autofocus when you push the Save
button half-way down. To enable the autofocus function of the Save button, select
(Settings) > Save options & storage > Save button half-press = Autofocus.
10.2 View from the left
10.2.1 Figure
10.2.2 Explanation
1. Digital camera.
2. Camera lamp.
#T559954; r. AP/42311/42335; en-US
19

FLIR T1020 Specifications

General

Resolution	1024 × 768 pixels
Detector Type	Uncooled microbolometer
Digital Camera	5 MP
Laser Pointer	Yes
Wi-Fi	Yes
Image Frequency	30 Hz
Detector Pitch	17 µm
Digital Zoom	1-8x continuous
Video Recording	Yes
Storage Media	SD card
Spectral Range	7.5 – 14 µm
Temperature Range	-40 °C to +2000 °C (-40 °F to +3632 °F)
Field of View	28° x 21°
Display	4.3 in LCD touchscreen, 800 × 480 pixels
Focus	Motorized and manual
Image Modes	Thermal, visual, MSX
Operating Temperature	-15 °C to +50 °C
Storage Temperature	-40 °C to +70 °C (-40 °F to +158 °F)
Connectivity	USB 2.0, HDMI
Image Storage	JPEG
Image Formats	JPEG
Thermal Sensitivity	<20 mK at 30°C
