FLIR T1020 User Manual

Technical data26
26.22 IR lens f=83.4 mm (12°) with case
P/N: T199077
Rev.: 39047
General description
The 12° lens provides approximately two times magnification compared to the standard 28° lens. This
lens is ideal for small or distant targets, such as overhead power lines.
Imaging and optical data
Field of view (FOV) 12° × 9° ( 15.2° diagonal)
Minimum focus distance 1.3 m (4.26 ft.)
Focal length 83.4 mm (3.28 in.)
Spatial resolution (IFOV) 0.20 mrad
Lens identification Automatic
F-number 1.2
Number of lenses 5 (5 asph)
Distortion 2.2%
Physical data
Weight 1.06 kg (2.34 lb.)
Size (L × D) 134.1 × 100.5 mm (5.28 × 3.96 in.)
Front lens diameter 75 mm (3.0 in.)
Shipping information
Packaging, type Cardboard box
List of contents
• Lens
• Lens case
• Front lens cap
• Rear lens cap
• Mounting instruction
Packaging, weight 1.4 kg (3.1 lb.)
Packaging, size 212 × 150 × 150 mm (8.35 × 5.91 × 5.91 in.)
EAN-13 7332558011010
UPC-12
845188011864
Country of origin Sweden
Compatible with the following products
• 72501-0101; FLIR T1020 12°
• 72501-0102; FLIR T1020 28°
• 72501-0103; FLIR T1020 45°
• 72501-0104; FLIR T1020 28° and 12°
• 72501-0105; FLIR T1020 28° and 45°
• 72501-0106; FLIR T1020 28°, 12°, and 45°
• 72501-0201; FLIR T1030sc 12°
• 72501-0202; FLIR T1030sc 28°
• 72501-0203; FLIR T1030sc 45°
• 72501-0301; FLIR T1040 12°
• 72501-0302; FLIR T1040 28°
• 72501-0303; FLIR T1040 45°
• 72501-0401; FLIR T1050sc 12°
• 72501-0402; FLIR T1050sc 28°
• 72501-0403; FLIR T1050sc 45°
#T559954; r. AP/42311/42335; en-US
184

FLIR T1020 Specifications

General

Resolution	1024 × 768 pixels
Detector Type	Uncooled microbolometer
Digital Camera	5 MP
Laser Pointer	Yes
Wi-Fi	Yes
Image Frequency	30 Hz
Detector Pitch	17 µm
Digital Zoom	1-8x continuous
Video Recording	Yes
Storage Media	SD card
Spectral Range	7.5 – 14 µm
Temperature Range	-40 °C to +2000 °C (-40 °F to +3632 °F)
Field of View	28° x 21°
Display	4.3 in LCD touchscreen, 800 × 480 pixels
Focus	Motorized and manual
Image Modes	Thermal, visual, MSX
Operating Temperature	-15 °C to +50 °C
Storage Temperature	-40 °C to +70 °C (-40 °F to +158 °F)
Connectivity	USB 2.0, HDMI
Image Storage	JPEG
Image Formats	JPEG
Thermal Sensitivity	<20 mK at 30°C
