FLIR T1020 User Manual

Technical data26
26.19 IR lens, f=36 mm (28°) with case
P/N: T199064
Rev.: 30226
General description
The standard 28° lens is suitable for the majority of applications.
Imaging and optical data
Field of view (FOV) 28° × 21° (34.5° diagonal)
Minimum focus distance 0.4 m (1.32 ft.)
Focal length 36 mm (1.42 in.)
Spatial resolution (IFOV) 0.47 mrad
Lens identification Automatic
F-number 1.15
Number of lenses 4 (4 asph)
Distortion 2.8%
Physical data
Weight 0.730 kg (1.61 lb.)
Size (L × D) 93.4 × 91 mm (3.68 × 3.58 in.)
Front lens diameter 64 mm (2.5 in.)
Shipping information
Packaging, type Cardboard box
List of contents
• Lens
• Lens case
• Front lens cap
• Rear lens cap
• Mounting instruction
Packaging, weight 1.1 kg (2.4 lb.)
Packaging, size 173 × 135 × 135 mm (6.81 × 5.31 × 5.31 in.)
EAN-13 7332558010983
UPC-12
845188011833
Country of origin Sweden
Compatible with the following products
• 72501-0101; FLIR T1020 12°
• 72501-0102; FLIR T1020 28°
• 72501-0103; FLIR T1020 45°
• 72501-0104; FLIR T1020 28° and 12°
• 72501-0105; FLIR T1020 28° and 45°
• 72501-0106; FLIR T1020 28°, 12°, and 45°
• 72501-0201; FLIR T1030sc 12°
• 72501-0202; FLIR T1030sc 28°
• 72501-0203; FLIR T1030sc 45°
• 72501-0301; FLIR T1040 12°
• 72501-0302; FLIR T1040 28°
• 72501-0303; FLIR T1040 45°
• 72501-0401; FLIR T1050sc 12°
• 72501-0402; FLIR T1050sc 28°
• 72501-0403; FLIR T1050sc 45°
#T559954; r. AP/42311/42335; en-US
181

FLIR T1020 Specifications

General

Resolution	1024 × 768 pixels
Detector Type	Uncooled microbolometer
Digital Camera	5 MP
Laser Pointer	Yes
Wi-Fi	Yes
Image Frequency	30 Hz
Detector Pitch	17 µm
Digital Zoom	1-8x continuous
Video Recording	Yes
Storage Media	SD card
Spectral Range	7.5 – 14 µm
Temperature Range	-40 °C to +2000 °C (-40 °F to +3632 °F)
Field of View	28° x 21°
Display	4.3 in LCD touchscreen, 800 × 480 pixels
Focus	Motorized and manual
Image Modes	Thermal, visual, MSX
Operating Temperature	-15 °C to +50 °C
Storage Temperature	-40 °C to +70 °C (-40 °F to +158 °F)
Connectivity	USB 2.0, HDMI
Image Storage	JPEG
Image Formats	JPEG
Thermal Sensitivity	<20 mK at 30°C
