FLIR T1020 User Manual

Terms, laws, and definitions
34
Term Definition
Radiative heat transfer Heat transfer by the emission and absorption of thermal
radiation
Reflected apparent temperature apparent temperature of the environment that is reflected by
the target into the IR camera
13
Spatial resolution ability of an IR camera to resolve small objects or details
Temperature measure of the average kinetic energy of the molecules and
atoms that make up the substance
Thermal energy total kinetic energy of the molecules that make up the
object
14
Thermal gradient gradual change in temperature over distance
13
Thermal tuning process of putting the colors of the image on the object of
analysis, in order to maximize contrast
#T559954; r. AP/42311/42335; en-US
210
13.Based on ISO 16714-3:2016 (en).
14.Thermal energy is part of the internal energy of an object.

FLIR T1020 Specifications

General

Resolution	1024 × 768 pixels
Detector Type	Uncooled microbolometer
Digital Camera	5 MP
Laser Pointer	Yes
Wi-Fi	Yes
Image Frequency	30 Hz
Detector Pitch	17 µm
Digital Zoom	1-8x continuous
Video Recording	Yes
Storage Media	SD card
Spectral Range	7.5 – 14 µm
Temperature Range	-40 °C to +2000 °C (-40 °F to +3632 °F)
Field of View	28° x 21°
Display	4.3 in LCD touchscreen, 800 × 480 pixels
Focus	Motorized and manual
Image Modes	Thermal, visual, MSX
Operating Temperature	-15 °C to +50 °C
Storage Temperature	-40 °C to +70 °C (-40 °F to +158 °F)
Connectivity	USB 2.0, HDMI
Image Storage	JPEG
Image Formats	JPEG
Thermal Sensitivity	<20 mK at 30°C
