Triggering on Waveforms
Triggering on Edges
5
49
The test tool will now have a screen like Figure 28.
6 Arm the test tool for a new single
shot.
Tip
The test tool stores all single shots in the replay
memory. Use the Replay function to look at all
the stored single shots.
Figure 28. Making a Single Shot Measurement
