Fluke 5700A Series User Manual

Calibration and Verification
Calibrating the 5700A/5720A Series II to External Standards 3
3-9
4. Enter the ambient temperature; then press E. The display shows:
PREV
MENU
IF3-4.EPS
5. Connect the 732B to the calibrator as shown in Figure 3-3.
732B DC STANDARD
AC PWR IN CAL CHARGE LOW BAT
10V 1.018V CHASSIS
GUARD1.018V COM10V COM
SERIAL NUMBER
HI
HI
LO
LO
HI
OUTPUT
V A
SENSE
V
AUX
CURRENT
GUARD
GROUND
WIDEBAND
ΩΩ
CALIBRATOR
VOLTAGE REFERENCE
STANDARD
F7-3.EPS
Figure 3-3. 732B External Calibration Connections.

Fluke 5700A Series Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% non-condensing
Frequency Range	10 Hz to 1 MHz
Accuracy	Varies by function and range. See manufacturer's specifications for details.
Output Stability	Varies by function and range. See manufacturer's specifications for details.
Power Requirements	50 Hz to 60 Hz
