Fluke 5700A Series User Manual

Introduction and Specifications
Electrical Specifications 1
1-41
1-35. Wideband AC Voltage (Option 5700-03) Specifications
Specifications apply to the end of the cable and 50 Ω termination used for calibration.
Range
Absolute Uncertainty
±5 °C from calibration temperature
30 Hz - 500 kHz
24 Hours 90 Days 180 Days 1 Year
Volts dBm
Resolution
± (% output +µV)
1.1 mV -46 10 nV 0.4 + 0.4 0.5 + 0.4 0.6 + 0.4 0.8 + 2
3 mV -37 10 nV 0.4 + 1 0.45 + 1 0.5 + 1 0.7 + 3
11 mV -26 100 nV 0.2 + 4 0.35 + 4 0.5 + 4 0.7 + 8
33 mV -17 100 nV 0.2 + 10 0.3 + 10 0.45 + 10 0.6 + 16
110 mV -6.2
1 µV
0.2 + 40 0.3 + 40 0.45 + 40 0.6 + 40
330 mV +3.4
1 µV
0.2 + 100 0.25 + 100 0.35 + 100 0.5 + 100
1.1 V +14
10 µV
0.2 + 400 0.25 + 400 0.35 + 400 0.5 + 400
3.5 V +24
10 µV
0.15 + 500 0.2 + 500 0.3 + 500 0.4 + 500
Amplitude Flatness, 1 kHz Reference
Voltage Range
1.1 mV 3 mV >3 mV
Frequency
(Hz)
Frequency
Resolution
(Hz)
± (% output + floor indicated)
Temperature
Coefficient
±ppm/°C
Settling Time
To Full
Accuracy
(Seconds)
Harmonic
Distortion
(dB)
10 - 30 0.01 0.3 0.3 0.3 100 7 -40
30 - 120 0.01 0.1 0.1 0.1 100 7 -40
120 - 1.2 k 0.1 0.1 0.1 0.1 100 5 -40
1.2 k - 12 k 1 0.1 0.1 0.1 100 5 -40
12 k - 120 k 10 0.1 0.1 0.1 100 5 -40
120 k - 1.2 M 100
0.2 + 3 µV 0.1 + 3 µV 0.1 + 3 µV
100 5 -40
1.2 M - 2 M 100 k
0.2 + 3 µV 0.1 + 3 µV 0.1 + 3 µV
100 0.5 -40
2 M - 10 M 100 k
0.4 + 3 µV 0.3 + 3 µV 0.2 + 3 µV
100 0.5 -40
10 M - 20 M 1 M
0.6 + 3 µV 0.5 + 3 µV 0.4 + 3 µV
150 0.5 -34
20 M - 30 M 1 M
1.5 + 15 µV 1.5 + 3 µV 1 + 3 µV
300 0.5 -34
Additional Operating Information:
dBm reference = 50 Ω
Range boundaries are at voltage points, dBm levels are approximate.
dBm = 10 log (
mW 1
Power
) ; 0.22361 V across 50 Ω = 1 mW or 0 dBm
Minimum Output ................................................... 300 µV (-57 dBm)
Frequency Uncertainty ......................................... ±0.01 %
Frequency Resolution .......................................... 11,999 counts to 1.1999 MHz, 119 counts to 30 MHz
Overload Protection.............................................. A short circuit on the wideband output will not result in damage. After
settling time, normal operation is restored upon removal.

Fluke 5700A Series Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% non-condensing
Frequency Range	10 Hz to 1 MHz
Accuracy	Varies by function and range. See manufacturer's specifications for details.
Output Stability	Varies by function and range. See manufacturer's specifications for details.
Power Requirements	50 Hz to 60 Hz
