1-36. Auxiliary Amplifier Specifications
For complete specifications, see the 5205A and 5220A Operators Manuals.
5205A (220V - 1100 V ac, 0 V - 1100 V dc)
Overshoot: < 10 %
Distortion (bandwidth 10 Hz - 1 MHz):
10 Hz - 20 kHz ................................................ 0.07 %
20 kHz - 50 kHz .............................................. 0.2 %
50 kHz - 100 kHz ............................................ 0.25 %
Frequency
(Hz)
90 Day Accuracy
at 23 ±5 °C
± (% output + % range)
Temperature Coefficient for
0 - 18 °C and 28 - 50 °C
± (ppm output + ppm range) / °C
0 dc
10 - 40
40 - 20 k
20 k - 50 k
50 k - 100 k
0.05 + 0.005
0.15 + 0.005
0.04 + 0.004
0.08 + 0.006
0.1 + 0.01
15 + 3
45 + 3
15 + 3
50 + 10
70 + 20
5220A (AC Current, 180-day specifications):
Accuracy:
20 Hz - 1 kHz ................................................. 0.07 % + 1 mA
1 kHz - 5 kHz .................................................. (0.07 % + 1mA) x frequency in kHz
Temperature Coefficient (0 - 18 °C and 28 - 50 °C):
(0.003 % + 100A) / °C
Distortion (bandwidth 300 kHz):
20 Hz - 1 kHz .................................................. 0.1% + 1 mA
1 kHz - 5 kHz .................................................. (0.1% + 1 mA) x frequency in kHz
Note: 5700A/5720A combined with 5220A is not specified for inductive loads.
