Fluke 5700A Series User Manual

Introduction and Specifications
Electrical Specifications 1
1-15
1-29. Electrical Specifications
Note
Fluke guarantees performance verification using specifications stated to
99% confidence level.
1-30. DC Voltage Specifications
5720A Series II DC Voltage Specifications
Absolute Uncertainty
± 5 °C from calibration temperature
[1]
Relative Uncertainty
± 1 °C
24 Hours 90 Days 180 Days 1 Year 24 Hours 90 Days
Range Resolution
± (ppm output + µV)
99 % Confidence Level
220 mV 10 nV 5 + 0.5 7 + 0.5 8 + 0.5 9 + 0.5 2 + 0.4 2.5 + 0.4
2.2 V 100 nV 3.5 + 0.8 4 + 0.8 4.5 + 0.8 6 + 0.8 2 + 0.8 2.5 + 0.8
11 V
1 µV
2.5 + 3 3 + 3 3.5 + 3 4 + 3 1 + 3 1.5 + 3
22 V
1 µV
2.5 + 5 3 + 5 3.5 + 5 4 + 5 1 + 5 1.5 + 5
220 V
10 µV
3.5 + 50 4 + 50 5 + 50 6 + 50 2 + 50 2.5 + 50
1100 V
100 µV
5 + 500 6 + 500 7 + 500 8 + 500 2.5 + 400 3 + 400
95 % Confidence Level
220 mV 10 nV 4 + 0.4 6 + 0.4 6.5 + 0.4 7.5 + 0.4 1.6 + 0.4 2 + 0.4
2.2 V 100 nV 3 + 0.7 3.5 + 0.7 4 + 0.7 5 + 0.7 1.6 + 0.7 2 + 0.7
11 V
1 µV
2 + 2.5 2.5 + 2.5 3 + 2.5 3.5 + 2.5 0.8 + 2.5 1.2 + 2.5
22 V
1 µV
2 + 4 2.5 + 4 3 + 4 3.5 + 4 0.8 + 4 1.2 + 4
220 V
10 µV
3 + 40 3.5 + 40 4 + 40 5 + 40 1.6 + 40 2 + 40
1100 V
100 µV
4 + 400 4.5 + 400 6 + 400 6.5 + 400 2 + 400 2.4 + 400
Notes:
DC Zeros calibration required every 30 days.
1. For fields strengths >1 V/m but ≤3 V/m, add 0.01 % of range.

Fluke 5700A Series Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% non-condensing
Frequency Range	10 Hz to 1 MHz
Accuracy	Varies by function and range. See manufacturer's specifications for details.
Output Stability	Varies by function and range. See manufacturer's specifications for details.
Power Requirements	50 Hz to 60 Hz
