Fluke 5700A Series User Manual

5700A/5720A Series II Calibrator
Service Manual
1-16
5700A Series II DC Voltage Specifications
Absolute Uncertainty
± 5 °C from calibration temperature
[1]
Relative Uncertainty
± 1 °C
24 Hours 90 Days 180 Days 1 Year 24 Hours 90 Days
Range Resolution
± (ppm output + µV)
99 % Confidence Level
220 mV 10 nV 6.5 + .75 7 + .75 8 + .75 9 + .8 2.5 + .5 4 + .5
2.2 V 100 nV 3.5 + 1.2 6 + 1.2 7 + 1.2 8 + 1.2 2.5 + 1.2 4 + 1.2
11 V
1 µV
3.5 + 3 5 + 4 7 + 4 8 + 4 1.5 + 3 3.5 + 4
22 V
1 µV
3.5 + 6 5 + 8 7 + 8 8 + 8 1.5 + 6 3.5 + 8
220 V
10 µV
5 + 100 6 + 100 8 + 100 9 + 100 2.5 + 100 4 + 100
1100 V
100 µV
7 + 600 8 + 600 10 + 600 11 + 600 3 + 600 4.5 + 600
95 % Confidence Level
220 mV 10 nV 5.5 + 0.6 6 + 0.6 7 + 0.6 8 + 0.6 2 + 0.4 3.5 + 0.4
2.2 V 100 nV 3.5 + 1 5 + 1 6 + 1 7 + 1 2 + 1 3.5 + 1
11 V 1 mV 3 + 3.5 4 + 3.5 6 + 3.5 7 + 3.5 1.2 + 3 3 + 3.5
22 V 1 mV 3 + 6.5 4 + 6.5 6 + 6.5 7 + 6.5 1.2 + 6 3 + 7
220 V 10 mV 4 + 80 5 + 80 7 + 80 8 + 80 2 + 80 3.5 + 80
1100 V 100 mV 6 + 500 7 + 500 8 + 500 9 + 500 2.4 + 500 4 + 500
Notes:
DC Zeros calibration required every 30 days.
1. For fields strengths >1 V/m but ≤ 3 V/m, add 0.01 % of range.

Fluke 5700A Series Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% non-condensing
Frequency Range	10 Hz to 1 MHz
Accuracy	Varies by function and range. See manufacturer's specifications for details.
Output Stability	Varies by function and range. See manufacturer's specifications for details.
Power Requirements	50 Hz to 60 Hz
