5700A/5720A Series II Calibrator
Service Manual
6-4
6-5. Service Centers
To locate a service center, use the information located in Contacting Fluke earlier in this
manual.
6-6. Parts List
The following pages contain a complete parts list for the 5700A/5720A Series II
Calibrators.
Manual Status Information
Ref or
Option
No.
Assembly Name
Fluke
Part No.
Revision
Level
A1 Keyboard PCA 761049 D
A2 Front Panel PCA 761031 102
A3 Analog Motherboard PCA 761023 104
A4 Digital Motherboard PCA 760942 101
A5 WideBand Output PCA 761346 108
A6 Wideband Oscillator PCA 761098 109
A7 Current/High-Resolution Oscillator PCA 764613 206
A8 Switch Matrix PCA 761106 108
A9 Ohms Cal PCA 775395 102
A10 Ohms Main PCA 761114 100
A11 DAC PCA 761122 110
A11A1 DAC Filter PCA 761395 B
A11A2 DAC Buffered Reference PCA 764639 A
A12 Oscillator Control PCA 761130 105
A13 Oscillator Output PCA 1607704 111
A13A1 Oscillator Wideband PCA 761403 103
A14 High Voltage Control PCA 775429 102
A15 High Voltage/High Current PCA 761155 103
A16 Power Amplifier PCA 761163 111
A16A1 Power Amplifier Digital Control SIP PCA 775320 C
A17 Regulator/Guard Crossing PCA 761171 107
A18 Filter/PA Supply PCA 761189 111
A19 Digital Power Supply PCA 761056 106
A20 CPU PCA (5700A Series I) 1591070 108
A20 CPU PCA (5700A Series II) 1639013 110
A20 CPU PCA (5720A) 1626228 108
A21 Rear Panel PCA 761221 104
A92 Oscillator Amp 761403 101
A93 DAC Filter 761395 B1
A95 Buffered Reference 764639 A1
