List of Replaceable Parts
Parts List
6
6-5
Table 6-1. Front Panel Final Assembly
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
A1 * KEYBOARD PCA 761049 1
A2 * FRONT PANEL PCA 761031 1
A3 * ANALOG MOTHERBOARD PCA 761023 1
A4 * DIGITAL MOTHERBOARD PCA 760942 1
A7 * CURRENT/HIGHT RESOLUTION OSCILLTOR. PCA 764613 1
A8 * SWITCH MATRIX PCA 761106 1
A9 * OHMS,CAL PCA 775395 1
A10 * OHMS,MAIN PCA 761114 1
A11 * DAC PCA 761122 1
A12 * OSCILLATOR CONTROL PCA 761130 1
A13 * OSCILLATOR OUTPUT, PCA 761148 1
A14 * HIGH VOLTAGE CONTROL PCA 775429 1
A15 * HIGH VOLTAGE/HIGH CURRENT PCA 761155 1
A16 * POWER AMPLIFIER PCA 761163 1
A17 * REGULATOR./GUARD CROSSING PCA 761171 1
A18 * FILTER/PA PCA 761189 1
A19 * DIGITAL POWER SUPPLY PCA 761056 1
A20 * CPU PCA (5700 Series I) 1591070 1
A20 * CPU PCA (5700 Series II) 1639013 1
A20 * CPU PCA (5720A) 1626228 1
A21 * REAR PANEL PCA 761221 1
A22 TRANSFORMER/MODULE ASSEMBLY 813527 1 1
CP1 ADAPTER,COAX,SMA(F),N(F) 516963 1
E1 JUMPER LINK,BINDING POST 190728 1
E2 GROUND STRIP,COPPER,1.00,.375,.030 854836 1
H5 SCREW,PH,P,THD FORM,STL,5-20,..312 494641 9
H20 SCREW,PH,P,LOCK,STL,4-40,.187 129882 4
H25 SCREW,CAP,SCKT,SS,8-32,.375 837575 4
H29 SCREW,FHU,P,LOCK,SS,6-32,.250 769893 3
H32 SCREW,PH,P,LOCK,STL,6-32,.250 152140 11
H43 SCREW,PH,P,LOCK,SS,6-32,.375 334458 1
MP1 PANEL, FRONT, SHEET METAL 761437 1
MP2 SHIELD, DISPLAY PWB 764514 1
MP3 LENS, SHIELD 760843 1
MP4 DECAL, FRONT OUTPUT CABLE DIAGRAM 802967 1
MP6 GROMMET,EXTRUDED,POLYETHYLENE,.085 854351 1
MP14 BINDING POST-RED 886382 3
MP17 BINDING POST-BLACK 886379 2
MP19 BINDING POST-GREEN 886374 1
MP20 BINDING POST-BLUE 886366 1
MP21 ENCODER WHEEL 764548 1
MP22 FRONT PANEL, MOLDED 886325 1
MP23 KNOB, ENCODER, GREY 868794 1
MP24 KEYPAD,ELASTOMERIC 1586631 1
MP25 DECAL, POWER ON/OFF 886312 1
MP26 DECAL, KEYPAD 886304 1
MP27 DECAL, FRONT OUTPUT 886309 1
MP28 NUT, #8 LOW THERMAL 850334 8
MP35 LENS, DISPLAY 600756 1
MP36 NAMEPLATE SET, ELECTROFORM (MODEL 5700A) 600723 1
MP36 NAMEPLATE SET, ELECTROFORM (MODEL 5720A) 600759 1
MP37 HANDLE,INSTRUMENT 886333 2
TM1 5700A/5720 OPERATOR MANUAL 601622 1
TM2 5700A/5720A SERVICE MANUAL 601630 1
TM3 5700A/5720A SERIES GUIDE SET 601960 1
1. See Figure 6-1a.
