Fluke 5700A Series User Manual

5700A/5720A Series II Calibrator
Service Manual
3-24
Table 3-2. List of Required Equipment for Main Output
Equipment Description Application
AC Measurement Standard or Fluke 5790A ACV, ACI
Resistance Standards Fluke 742A Series Cal, Ohms, DCI
Reference Divider Fluke 752A DC V
Null Detector EM Electronics N11 (Fluke 845A) DC V
Shunt Adapter Fluke 792A-7004 AC I
Calibrator Fluke 55X0A Ohms
Frequency Counter Philips PM6669 Frequency
Shunts Fluke A40 Series AC I
High Current Shunt Fluke Y5020 DC I
Resistance Standard L&N 0.1Ω 4221B DC I
DMM Wavetek 1281 or HP 3458A Ohms, DCI, ACI, AC V
Low Thermal Cables Fluke 5440A-7002 (5700A) or
5440A-7003 (5720A or 5700A)
Various
Equipment Required for Wideband Ac Module (Option 5700-03) Verification
Equipment Description Application
AC Measurement Standard Fluke 5790A with Wideband
Option -03
Wideband
Wideband Cable (supplied with
5700A-03)
Fluke Cable Wideband
50Ω Termination (supplied with
5700A-03)
Fluke Termination Wideband
Adapter (supplied with 5700A-03) Pomona 1269 BNC(F) to dual banana
plug
Wideband
Adapter Kings KN-99-46 N(F) to BNC(M) Wideband
Equipment Required for Optional Tests
Equipment Description Application
Oscilloscope Mainframe Tektronix 7000 Series HF Noise
Differential Amplifier Tektronix 7A22 HF Noise
Distortion Analyzer Krohn-Hite 6900B AC V, ACI, Distortion
Spectrum Analyzer HP 8590A AC V, Wideband
Distortion
Kelvin Varley Divider Fluke 720A DC V Linearity

Fluke 5700A Series Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% non-condensing
Frequency Range	10 Hz to 1 MHz
Accuracy	Varies by function and range. See manufacturer's specifications for details.
Output Stability	Varies by function and range. See manufacturer's specifications for details.
Power Requirements	50 Hz to 60 Hz
