Fluke 5700A Series User Manual

5700A/5720A Series II Calibrator
Service Manual
3-56
Table 3-20. Direct Current Accuracy Test Record (5720A)
Characterizing dc DMM @ ±200 mV and ±2.0V
Output
Current
Std
Res
Value
DC DMM
Setting
Rdg.
Column A
Std Res
Correction
(ppm)
Column B
UUT Error
Reading
(ppm)
UUT Actual
Error (A+B)
(ppm)
Test Limit,
90-day
(±ppm)
+2A 0.1Ω (200 mV) 118
-2A 0.1Ω (200 mV) 118
+200 mA 1.0Ω (200 mV) 57
-200 mA 1.0Ω (200 mV) 57
+20 mA 10Ω (200 mV) 38
-20 mA 10Ω (200 mV) 38
+2 mA 1 kΩ (2V) 39
-2 mA 1 kΩ (2V) 39
+200 µA 10 kΩ (2V) 49
-200 µA 10 kΩ (2V) 49

Fluke 5700A Series Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% non-condensing
Frequency Range	10 Hz to 1 MHz
Accuracy	Varies by function and range. See manufacturer's specifications for details.
Output Stability	Varies by function and range. See manufacturer's specifications for details.
Power Requirements	50 Hz to 60 Hz
