Fluke 5700A Series User Manual

Calibration and Verification
Determining Test Limits for Other Calibration Intervals 3
3-59
Table 3-23. 5720A AC Voltage Test Record (cont)
Output
Level
Frequency
Error
Display
Reading
Spec
(± ppm )
5790A
1-Year
Spec
(± ppm)
TUR GB
Factor
Test Limit (4)
(± ppm)
200V 1 kHz 64 31 2.05 0.936 59
200V 20 kHz 64 31 2.05 0.936 59
200V 50 kHz 101 69 1.46 0.875 88
200V 100 kHz 185 98 1.89 0.923 171
200V(2) 40 Hz 64 31 2.05 0.936 59
200V 20 Hz 110 68 1.62 0.896 99
200V 10 Hz 295 200 1.48 0.878 259
300V(3) 20 kHz 145 41 3.54 .993 144
600V(3) 50 kHz 378 130 2.91 .977 369
600V(3) 100 kHz 1375 500 2.21 .945 1299
1 kV 1 kHz 79 38 2.08 0.938 74
1 kV 50 Hz 79 38 2.08 0.938 74
1 kV 300 Hz 79 38 2.08 0.938 74
1 kV(3) 20 kHz 131 38 3.45 .991 130
1 kV(3) 30 kHz 371 130 2.85 .975 362
1 kV(3) 40 Hz 84 38 2.21 .945 79
1: This is a test of the bottom of the 20V range .
2: Observe the Calibrator output for 10 minutes and verify that it remains stable within ± 7.5 ppm.
3: Perform only for units that are used with a 5725A Amplifier.
4: When the TUR (Test Uncertainty Ratio) is less than 4:1, the spec is reduced to give the same
Consumer Risk as a 4:1 TUR as described later in this chapter.
