Fluke 5700A Series User Manual

5700A/5720A Series II Calibrator
Service Manual
3-66
Table 3-31. Wideband Accuracy at 1 kHz Test Record
Output
Level
Measured
Error
Spec
± ppm (90-day)
5790A
1-Year Spec
± ppm
TUR GB
Factor
Test
Limit
2.1V 2238 24 93 1.000 2238
1.0V 2900 24 121 1.000 2900
0.3V 2833 38 74.5 1.000 2833
0.1V 3400 53 64.1 1.000 3400
30 mV 3333 115 29.0 1.000 3333
10 mV 3900 240 16.2 1.000 3900
3 mV 4833 643 7.5 1.000 4833
1 mV 5400 1720 3.14 0.980 5292
Table 3-32. Wideband Flatness Test Record
Output
Level
Frequency
Measured
Flatness Error
Spec
± ppm
(90-day)
5790A
1-Year
Spec
TUR GB
Factor
Test Limit
± ppm
3V 10 Hz 3000 1000 3.00 0.980 2940
30 Hz 1000 300 3.33 0.988 988
10 kHz 1000 300 3.33 0.988 988
120 kHz 1000 300 3.33 0.988 988
500 kHz 1000 300 3.33 0.988 988
2 MHz 1000 500 2.00 0.932 932
5 MHz 2000 1000 2.00 0.932 1864
10 MHz 2000 1000 2.00 0.932 1864
20 MHz 4000 1500 2.67 0.968 3872
30 MHz 10000 3500 2.86 0.975 9750
1V 10 kHz 1000 300 3.33 0.988 988
120 kHz 1000 300 3.33 0.988 988
500 kHz 1000 300 3.33 0.988 988
2 MHz 1000 500 2.00 0.932 932
5 MHz 2000 1000 2.00 0.932 1864
10 MHz 2000 1000 2.00 0.932 1864
20 MHz 4000 1500 2.67 0.968 3872
30 MHz 10000 3500 2.86 0.975 9750
300 mV 10 kHz 1000 300 3.33 0.988 988
120 kHz 1000 300 3.33 0.988 988
500 kHz 1000 300 3.33 0.988 988
2 MHz 1000 500 2.00 0.932 932
5 MHz 2000 1000 2.00 0.932 1864
10 MHz 2000 1000 2.00 0.932 1864
20 MHz 4000 1500 2.67 0.968 3872
30 MHz 10000 3500 2.86 0.975 9750
100 mV 10 kHz 1000 400 2.50 0.961 961
120 kHz 1000 400 2.50 0.961 961
500 kHz 1030 400 2.58 0.964 993
2 MHz 1030 500 2.06 0.936 964
5 MHz 2030 1000 2.03 0.933 1894
10 MHz 2030 1000 2.03 0.933 1894
20 MHz 4030 1500 2.69 0.970 3909
30 MHz 10030 3500 2.87 0.976 9789

Fluke 5700A Series Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% non-condensing
Frequency Range	10 Hz to 1 MHz
Accuracy	Varies by function and range. See manufacturer's specifications for details.
Output Stability	Varies by function and range. See manufacturer's specifications for details.
Power Requirements	50 Hz to 60 Hz
