Fluke 5700A Series User Manual

5700A/5720A Series II Calibrator
Service Manual
6-10
Table 6-1. Rear Panel Final Assembly
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
F1 FUSE,.25X1.25,1.25A,250V,SLOW 851936 1
H1 FILTER, AIR 813493 1
H3 SCREW,CAP,SCKT,SS,8-32,.375 837575 4
H7 SCREW,PH,P,LOCK,STL,6-32,.750 114223 6
H13 SCREW,PH,P,LOCK,STL,6-32,.250 152140 1
MP1 REAR PANEL 886387 1
MP2 GROMMET,EXTRUDED,POLYETHYLENE,.085 854351 1
MP3 DECAL, REAR OUTPUT CABLE DIAGRRAM 886291 1
MP5 GROMMET,NYLON,NAT,.056X.150X.100X.155 285254 1
MP11 CONN ACC,MICRO-RIBBON,JACK SCREW 681940 2
MP13 CONN ACC,D-SUB,JACK SCREW,4-40 448092 8
MP21 ALUMINUM REAR OUTPUT HOUSING 885462 1
MP22 MOLDED HOUSING, REAR OUTPUT 886358 1
MP23 DECAL, REAR OUTPUT 886296 1
MP24 FILTER FRAME 886390 1
MP25 NUT, #8 LOW THERMAL 850334 6
MP31 HANDLE,INSTRUMENT 886333 2
MP33 BINDING POST-RED 886382 2
MP35 BINDING POST-BLACK 886379 2
MP37 BINDING POST-BLUE 886366 1
MP38 BINDING POST-PURPLE 886361 1
MP43 WASHER,FLAT,SS,.119,.187,.010 853296 8
MP51 WASHER, LOW THERMAL 760892 4
MP55 NUT, LOW THERMAL 760876 2
MP106 WASHER,FLAT,STL,.191,.289,.010 111047 2
MP125 WASHER,FLAT,STL,.160,.281,.010 111005 6
W1 CORD,LINE,5-15/IEC,3-18AWG,SVT,7.5 FT06 284174 1
W2 AC LINE FILTER ASSY 775445 1

Fluke 5700A Series Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% non-condensing
Frequency Range	10 Hz to 1 MHz
Accuracy	Varies by function and range. See manufacturer's specifications for details.
Output Stability	Varies by function and range. See manufacturer's specifications for details.
Power Requirements	50 Hz to 60 Hz
