Fluke 5700A Series - Page 393

List of Replaceable Parts
Parts List
6
6-15
Table 6-3. A2 Front Panel PCA (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
U12 * IC,CMOS,DUAL D F/F,+EDG TRG,SOIC 782995 1
U13 * IC,TTL,HEX INVERTER,W/OPEN COLL,SOIC 741249 1
U14-23 * IC,BIMOS,DISPLAY DRIVER,80V,PLCC 741231 10
U24 * IC,CMOS,PLD,PROGRAMD,5700A-90724,PLCC 837369 1
VR3,VR4 * ZENER,UNCOMP,6.2V,5%,60.5MA,1.5W,SMB 886700 2
VR5 * ZENER,UNCOMP,5.1V,5%,20MA,0.2W,SOT-23 837179 1
W1 CABLE, MOTHERBOARD TO DISPLAY 802694 1
