List of Replaceable Parts
Parts List
6
6-17
Table 6-4. A3 Analog Motherboard PCA
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
C1 CAP,POLYES,0.1UF,+-10%,50V 649913 1
C2 CAP,CER,1000PF,+-20%,50V,X7R 697458 1
C3 CAP,TA,1UF,+-20%,35V 697417 1
C4 CAP,TA,4.7UF,+-20%,25V 807644 1
C5 CAP,POLYES,0.47UF,+-10%,50V 697409 1
CR1,CR2 * DIODE,SI,BV=75V,IO=150MA,500MW 203323 2
H1,H2 SCREW,PH,P,LOCK,STL,6-32,.250 152140 2
H3-5 CABLE ACCESS,TIE,4.00L,.10W,.75 DIA 172080 3
J101,J111,J201,
J202,J211,J212,
J301,J302,J311,
J312,J401,J402,
J501,J502,J511,
J512,J601,J602,
J611,J612,J701,
J702,J801,J802,
J901,J902
CONN,DIN41612,TYPE C,64 SCKT 807818
807818
807818
807818
807818
807818
807818
807818
807818
26
J71 FIBER OPTIC,RECEIVER,1MBD 822148 1
J72 FIBER OPTIC,TRANSMITTER,1MBD 822155 1
J81,J82 SOCKET,1 ROW,PWB,.156CTR,10 POS 851183
851183
4
K1-3 RELAY,ARMATURE,2 FORM C,4.5VDC 783746 3
K4,K5,K9, K10 RELAY,REED,1 FORM A,5VDC 806950 4
K6-8,K11 RELAY,ARMATURE,2 FORM C,5V 733063 4
K12 RELAY,REED,1 FORM B,5VDC 845164 1
K13 RELAY,ARMATURE,2 FORM C,5V,LATCH 769307 1
MP3-54 RIVET,S-TUB,OVAL,AL,.087,.250 838482 52
MP55,MP56 SPACER,BROACH,.281 RND,STL,6-3 414508 2
MP57-61 SPACER,BROACH,SNAP,BR,.250 820613 5
MP62-66 CLAMP,CABLE,ADHESIVE,NYLON,.125 854273 5
MP101-128 CONN ACC,DIN41612,KEY 832733 28
R1 RES,CF,75,+-5%,0.25W 441642 1
R2 RES,CF,91,+-5%,0.25W 441683 1
RV1 VARISTOR,22V,+-20%,1.0MA 500777 1
W1 CABLE, FRONT/REAR 802835 1
W2 CABLE ASSY, MOTHERBOARD BUS, FRONT 859926 1
W3 CABLE ASSY, MOTHERBOARD BUS, REAR 859934 1
W8 CABLE, KEYBOARD/REAR PANEL 802710 1
W11 CABLE, BOOST 802744 1
XK1-3 RELAY SOCKET,4 POLE 441964 3
