List of Replaceable Parts
Parts List
6
6-19
Table 6-5. A4 Digital Motherboard PCA
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
C1,C4 CAP,TA,10UF,+-20%,35V 816512 2
C2 CAP,CER,1000PF,+-20%,50V,X7R 697458 1
C3 CAP,POLYES,0.1UF,+-10%,50V 649913 1
C5 CAP,POLYES,0.1UF,+-20%,250VAC 542233 1
C6 CAP,CER,6800PF,+-5%,100V,C0G 816710 1
CR3,CR4 DIODE,SI,100 PIV,1.0 AMP 698555 2
F1 FUSE,.25X1.25,3A,250V,SLOW 109280 1 1
H8-14 CABLE ACCESS,TIE,4.00L,.10W,.75 DIA 172080 7
H19,H20 SCREW,PH,P,LOCK,SS,4-40,.187 149567 2 2
H21,H22 WASHER,FLAT,STL,.093,.219,.020 306415 2
J11 HEADER,1 ROW,.156CTR,12 PIN 813362 1
J13 HEADER,1 ROW,.156CTR,10 PIN 446724 1
J14 HEADER,1 ROW,.156CTR,16 PIN 831370 1
J15 HEADER,1 ROW,.156CTR,14 PIN 831362 1
J16 HEADER,1 ROW,.156CTR,8 PIN 385435 1
J21 CONN,DIN41612,TYPE C,RT ANG,64 PIN 853437 1
J31 HEADER,1 ROW,.156CTR,RT ANG,5 PIN 844717 1
J41,J61,J62 CONN,DIN41612,TYPE C,64 SCKT 807818 3
J51,J52 HEADER,1 ROW,.100CTR,3 PIN 845334 2
J73 FIBER OPTIC,TRANSMITTER,1MBD 822155 1
J74 FIBER OPTIC,RECEIVER,1MBD 822148 1
J91 HEADER,2 ROW,.100CTR,34 PIN 851696 1
MP1 HLDR PART,FUSE,BODY,PWB MT 602763 1
MP2 HLDR PART,FUSE,CAP,1/4X1-1/4 460238 1
MP3-10 RIVET,S-TUB,OVAL,AL,.087,.250 838482 8
MP11 RIVET,S-TUB,OVAL,AL,.087,.343 838458 2
MP16 BRACKET, POWER SWITCH 885710 1 2
MP17,MP18,
MP20
SPACER,SWAGED,.312 RND,BR,.177 837864
837864
3
MP22,MP23 FOOT,RUBBER,ADHES,GRY,.44 DIA,.20 THK 1601870 2
MP24-26 SPACER,BROACH,SNAP,AL,.187 820639 3
P81,P82 HEADER,1 ROW,.156CTR,20 PIN 831222 2
R1 RES,CF,91,+-5%,0.25W 441683 1
R2,R3 RES,WW,2,+-1%,.7W 255646 2
R4 RES,CF,68,+-5%,0.25W 414532 1
RV1 VARISTOR,22V,+-20%,1.0MA 500777 1
RV2 VARISTOR,430V,+-10%,1.0MA 519355 1
SW1 SWITCH,PUSHBUTTON,DPST,PUSH-PUSH 665513 1 2
SW2-4 SWITCH,SLIDE,DPDT,LINE SELECT,RT ANG 817353 3
W15 CABLE, FIBER OPTIC 802769 1
W90 CABLE, REAR PANEL-CPU 802728 1
1. Fuse PN 109280 is for 100-120 volt configuration. For 200-230 volt configuration order PN 109231.
2. 3 parts make up assembly 665513
To Next Page
