List of Replaceable Parts
Parts List
6
6-23
Table 6-6. A5 Wideband Output PCA, Option -03 (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
R69,R70 RES,MF,249,+-1%,0.5W,100PPM 241281 2
R72,R73,R80-83 RES,MF,909,+-1%,0.5W,100PPM 178053 6
R74 RES,CF,20K,+-5%,0.25W 441477 1
R75 RES,MF,10K,+-1%,0.125W,100PPM 168260 1
R78,R79,R86-89 RES,MF,12.7,+-1%,0.125W,100PPM 441766 6
R92-95 RES,MF,75,+-1%,0.125W,100PPM 306027 4
R96-99 RES,MF,187,+-0.1%,0.5W,25PPM 807750 4
R100 RES,MF,1.21K,+-1%,0.125W,100PPM 229146 1
R101 RES,MF,1.43K,+-1%,0.125W,25PPM 447995 1
R107 RES,CF,100,+-5%,0.25W 810465 1
R108 RES,MF,49.9,+-1%,0.125W,100PPM 820266 1
R109 RES,MF,2.15K,+-1%,0.125W,50PPM 347039 1
R110 RES,MF,1K,+-0.1%,0.125W,25PPM 340380 1
R115 RES,CF,200K,+-5%,0.25W 441485 1
R116 RES,MF,2K,+-1%,0.125W,100PPM 816629 1
R117 RES,MF,1.69K,+-1%,0.125W,100PPM 321414 1
R118 RES,CF,1.5K,+-5%,0.25W 810432 1
R119 RES,MF,8.06K,+-1%,0.125W,100PPM 817619 1
R120 RES,MF,124,+-1%,0.125W,100PPM 343905 1
R122 RES,MF,4.99K,+-1%,0.125W,100PPM 721548 1
TP1-19 JUMPER,WIRE,NONINSUL,0.200CTR 816090 19
U1 * RMS CONVERTER TESTED 400 OHM-B 767707 1
U2,U12 * IC,OP AMP,DUAL,PRECISION,8-PIN 783696 2
U3 * IC,ARRAY,5 TRANS,NPN,3 ISO,2 DIFF CON 248906 1
U4 * IC,COMPARATOR,DUAL,LO-PWR,8 PIN DIP 478354 1
U5 * IC,OP AMP,LO-OFFSET VOLTAGE,LO-NOISE 605980 1
U6 * IC,BIMOS,8 CHNL HI-VOLT DRVR W/LATCH 782912 1
U7 * IC,CMOS,PROGRMBL PERIPHERAL INTERFACE 780650 1
U8 * IC,CMOS,8-1 LINE MUX/DEMUX ANALOG SW 836304 1
U9,U10 * IC,BIMOS,4 CHNL HI-VOLT DRVR W/LATCH 820514 2
U11 * IC,OP AMP,DUAL,LO OFFST VOLT,LO-DRIFT 851704 1
VR1 * ZENER,UNCOMP,9.1V,5%,20MA,0.5W 853788 1
VR2 * ZENER,COMP,6.4V,2%,2PPM,1MA 419036 1
VR3 * ZENER,UNCOMP,16.0V,5%,15.5MA,1.0W 313221 1
VR4 * ZENER,UNCOMP,5.6V,5%,20MA,0.5W 277236 1
W1 CABLE, WIDEBAND OUTPUT INTERCONNECT 802876 1
W2 CABLE ASSY,50 OHM,COAX,N(M),3FT 853432 1
Z1 * RNET,CERM,SIP 5700 ATTENUATOR 760728 1
Z2 * RNET,CERM,SIP,5700 ATTENUATOR 760769 1
