Fluke 5700A Series User Manual

List of Replaceable Parts
Parts List
6
6-29
Table 6-8. A7 Current/High-Res Oscillator PCA
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
C1,C71 CAP,CER,0.22UF,+80-20%,50V,Z5U 649939 2
C2,C3,C18-20,
C29,C32-35,C47,
C48,C50,C51,
C55,C56
CAP,POLYES,0.1UF,+-10%,50V 649913
649913
649913
649913
16
C4,C5 CAP,CER,100PF,+-2%,100V,C0G 812115 2
C6,C7,C21-24,
C37,C38,C40,
C43,C52,C53,
C60,C61
CAP,TA,4.7UF,+-20%,25V 807644
807644
807644
807644
14
C8 CAP,CER,18PF,+-2%,100V,C0G 830638 1
C9 CAP,CER,47PF,+-20%,50V,C0G 706705 1
C10 CAP,CER,470PF,+-5%,50V,C0G 830430 1
C11 CAP,CER,4700PF,+-20%,100V,C0G 743427 1
C12,C13,C70 CAP,AL,47UF,+-20%,50V,SOLV PROOF 822403 3
C14 CAP,AL,6.8UF,+-20%,35V,SOLV PROOF 643189 1
C15 CAP,TA,2.2UF,+-20%,16V 706804 1
C16 CAP,CER,1000PF,+-2%,50V,C0G 807966 1
C17,C45,C46,
C54
CAP,CER,33PF,+-5%,50V,C0G 714543
714543
4
C25,C26,C30,
C36,C41,C42,
C49
CAP,POLYES,0.047UF,+-10%,50V 820548
820548
820548
7
C27,C28 CAP,POLYES,1UF,+-10%,50V 733089 2
C31,C67 CAP,POLYES,0.22UF,+-5%,50V 747519 2
C39 CAP,TA,22UF,+-20%,25V 845149 1
C44 CAP,CER,15PF,+-20%,50V,C0G 697524 1
C57,C58 CAP,CER,2000PF,+-5%,50V,C0G 832618 2
C59 CAP,CER,390PF,+-2%,50V,C0G 820530 1
C62 CAP,CER,820PF,+-2%,50V,C0G 631002 1
C65,C66 CAP,CER,82PF,+-2%,100V,C0G 512350 2
C68 CAP,CER,150PF,+-5%,100V,C0G 512988 1
C69 CAP,CER,27PF,+-2%,100V,C0G 816652 1
CR1,CR2, CR10,
CR11
*
*
DIODE,SI,BV=125V,IO=150MA,500 MW 844647
844647
4
CR3,CR4 * DIODE,SI,BV=75V,IO=150MA,500MW 659516 2
CR9 DIODE,SI,VARACTOR,PIV=28V,500PF 2149283 1
CR12,CR13 DIODE,SI,BV=200V,IO=200MA 876867 2
E1,E2 JUMPER,WIRE,NONINSUL,0.200CTR 816090 2
H1-4 RIVET,S-TUB,OVAL,AL,.087,.343 838458 4
HR2 * RN/HYBRID CURRENT HYBRID 775387 1
K1-3,K6 K7,K10-
13,K16
RELAY,ARMATURE,2 FORM C,5V,LATCH 769307
769307
10
K4,K5,K8,K9 RELAY,ARMATURE,4 FORM C,5V,LATCH 715078 4
K14,K15,K17 RELAY,ARMATURE,2 FORM C,5V 733063 3
L1-3,L5,L7-9 CHOKE,6TURN 320911 7
L4 INDUCTOR,3.3UH,+-10%,88MHZ,SHLD 598219 1
L10 INDUCTOR,1UH,+-5%,156MHZ,SHLD 806562 1
L11 INDUCTOR,150UH,+-5%,10.5MHZ,SHLD 174763 1
L12 INDUCTOR,6800UH,+-10%,1.5MHZ,SHLD 363184 1
MP1-5 HEAT DIS,PWB MT,.75X.50X.50,TO-220 816587 5 1,2
MP6 MOLDED COVER, HYBRID, R-NET 775619 1
MP7,MP8 SHIELD, HIGH RES, FRONT 775684 2
MP9,MP10 SHIELD, HIGH RES, REAR 764589 2
MP11,MP12 EJECTOR,PWB,NYLON 494724 2
P211,P212 CONN,DIN41612,TYPE C,RT ANG,64 PIN 807800 2
Q1 * TRANSISTOR,SI,BV=40V,40W,TO-22 665448 1 1

Fluke 5700A Series Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% non-condensing
Frequency Range	10 Hz to 1 MHz
Accuracy	Varies by function and range. See manufacturer's specifications for details.
Output Stability	Varies by function and range. See manufacturer's specifications for details.
Power Requirements	50 Hz to 60 Hz
