List of Replaceable Parts
Parts List
6
6-33
Table 6-9. A8 Switch Matrix PCA
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
C1,C3,C18 CAP,CER,470PF,+-10%,50V,C0G 733071 3
C2,C5 CAP,CER,33PF,+-5%,50V,C0G 714543 2
C4 CAP,CER,0.01UF,+80-20%,50V,Z5V 697284 1
C6-9,C12 C13,
C15,C16 C21,
C25-27
CAP,POLYES,0.22UF,+-5%,50V 747519
747519
747519
12
C10,C29 CAP,CER,100PF,+-20%,50V,C0G 721605 2
C14 CAP,CER,15PF,+-2%,100V,C0G 832287 1
C17 CAP,POLYES,1UF,+-10%,50V 733089 1
C20 CAP,CER,1000PF,+-20%,50V,X7R 697458 1
C22 CAP,TA,15UF,+-20%,20V 807610 1
C23 CAP,CER,22PF,+-2%,50V,C0G 714832 1
C30 CAP,CER,330PF,+-5%,50V,C0G 697441 1
C31 CAP,POLYES,0.1UF,+-10%,50V 649913 1
C32 CAPACITOR R05R,CAP,CER,220PF,+-20%,50V,C0G 740654 1
CR1,CR3,CR4,
CR7-9
*
*
DIODE,SI,BV=75V,IO=150MA,500MW 659516
659516
6
CR2,CR10 DIODE,SI,100 PIV,1.0 AMP 698555 2
CR5,CR6,CR12,
CR13
*
*
DIODE RL1N4007R05A,DIODE,SI,1KV,1A,DO-41
844647
844647
4
CR14,CR15 DIODE,SI,100 PIV,1 AMP 887203 2
R1 HYBRID ASSEMBLY, TESTED 813436 1
H5-8 RIVET,S-TUB,OVAL,AL,.087,.343 838458 4
K1,K3-6 K13,
K15-20, K22,
K24,K25
RELAY,ARMATURE,4 FORM C,5V,LATCH 715078
715078
715078
15
K2,K7-12,K14,
K21,K23 K26-33
RELAY,ARMATURE,2 FORM C,5V,LATCH 769307
769307
18
L1-4 CHOKE,6TURN 320911 4
MP2 MOLDED COVER, HYBRID, R-NET 775619 1
MP9,MP10 EJECTOR,PWB,NYLON 494724 2
MP18-21 SPACER,.156 RND,SOLUBLE,.062,.060 296319 8
P201,P202 CONN,DIN41612,TYPE C,RT ANG,64 PIN 807800 2
Q1 * TRANSISTOR,SI,BV=60V,65W,TO-22 386128 1
Q2 * TRANSISTOR,SI,NPN,SMALL SIGNAL 698225 1
Q4 * TRANSISTOR,SI,PNP,40V,0.35W,TO-92 698233 1
Q6,Q7,Q11 * TRANSISTOR,SI,N-DMOS PWR FET,T0-92 782565 3
Q9,Q10 * TRANSISTOR,SI,N-JFET,TO92 845073 2
Q12,Q13 * TRANSISTOR,SI,N-JFET,HI-VOLTAG 832147 2
R1 RES,MF,15.4K,+-1%,0.125W,100PPM 772038 1
R2 RES,MF,1.21K,+-1%,0.125W,100PPM 810507 1
R3,R4,R6 RES,CF,10K,+-5%,0.25W 697102 3
R5,R7,R10,R19,
R34
RES,MF,1K,+-1%,0.125W,100PPM 816595
816595
5
R8 RES,MF,12.7K,+-1%,0.125W,25PPM 817510 1
R9,R46,R47 RES,MF,10K,+-0.1%,0.125W,50PPM 733972 3
R11,R20,R35 RES,CF,560,+-5%,0.25W 810440 3
R12 RES,CF,1.5,+-5%,0.25W 732800 1
R13 RES,CF,330,+-5%,0.25W 830596 1
R14 RES,CF,4.7K,+-5%,0.25W 721571 1
R15-17,R21 RES,CF,100K,+-5%,0.25W 658963 4
R18,R33,R44 RES,MF,20K,+-0.1%,0.25W,25PPM 810564 3
R22 RES,CF,1K,+-5%,0.25W 780585 1
R23,R39,R40 RES,CF,100,+-5%,0.25W 810465 3
R24 1/4 WATT HERM. W.W. RESISTOR 864207 1
R25 RES,CF,6.2K,+-5%,0.25W 714337 1
R26 RES,CF,9.1K,+-5%,0.25W 706663 1
