List of Replaceable Parts
Parts List
6
6-39
Table 6-11. A10 Ohms Main PCA
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
C1,C2,C7 C10-
13,C16
CAP,POLYES,0.22UF,+-5%,50V 747519
747519
8
C3,C4 CAP,TA,10UF,+-20%,35V 816512 2
C6 CAP,TA,4.7UF,+-20%,25V 807644 1
H3-6 RIVET,S-TUB,OVAL,AL,.087,.343 838458 4
H7,H8 SCREW,PH,P,LOCK,STL,6-32,.250 152140 2
K1-4,K7,K9,K10,
K13-17,K28-30,
K33-37
RELAY,ARMATURE,2 FORM C,5V,LATCH 769307
769307
769307
20
K5 RELAY,REED,1 FORM A,5VDC 806950 1
K6,K8,K11,K12 RELAY,REED,1 FORM A,4.5VDC 544031 4
K18-27,K31 K32,
K39
RELAY,ARMATURE,4 FORM C,5V,LATCH 715078
715078
13
K38 RELAY,ARMATURE,2 FORM C,5V 733063 1
L4,L5 CHOKE,6TURN 320911 2
MP1,MP2 SPACER,SWAGE,.250 RND,BR,6-32,.875 266486 2
MP3,MP4 EJECTOR,PWB,NYLON 494724 2
MP6 FOOT,RUBBER,ADHES,BLK,.50 SQ,.12 THK 543488 1
MP7 * OHMS, MAIN, HEAT SHIELD 872325 1
P301,P302 CONN,DIN41612,TYPE C,RT ANG,64 PIN 807800 2
R1 R-NET, THIN FILM, TESTED, FRIT 103306 1
R2,R3 RES,CF,270,+-5%,0.25W 810424 2
R5 RES,CF,100,+-5%,0.25W 810465 1
R6 RES,MF,110K,+-1%,0.125W,100PPM 234708 1
TP1-5 JUMPER,WIRE,NONINSUL,0.200CTR 816090 5
U1 * IC,OP AMP,JFET INPUT,LOW NOISE 807933 1
U2,U3 U5-8,
U11-13
*
*
IC,BIMOS,8 CHNL HI-VOLT DRVR W/LATCH 782912
782912
9
U9 * IC,CMOS,BCD-DEC & BINRY-OCTAL DECODER 650689 1
U10 * IC,CMOS,3-8 LINE DCDR W/ENABLE 773036 1
VR1 * ZENER,UNCOMP,3.3V,5%,20.0MA,0.4W 820423 1
Z1 * RNET,MF,HERM,SIP,5700 RESISTANCE REF 798330 1
Z2 * RNET,MF,HERM,SIP,5700 RESISTANCE REF 759753 1
Z3 * RNET,MF,HERM,SIP,5700 RESISTANCE REF 759803 1
