5700A/5720A Series II Calibrator
Service Manual
6-42
Table 6-12. A11 DAC PCA (cont)
Reference
Designator
Description Fluke Stock
No
Tot
Qty
Notes
MP31 MOLDED COVER, REF. HYBRID 797746 1
P401,P402 CONN,DIN41612,TYPE C,RT ANG,64 PIN 807800 2
Q1 * TRANSISTOR,SI,BV=60V,65W,TO-220 386128 1
Q2,Q3 * TRANSISTOR,SI,BV=40V,40W,TO-220 369660 2 1
Q4-7,Q11,Q22,
Q25,Q26
*
*
TRANSISTOR,SI,N-DMOS PWR FET,T0-92 782565
782565
8
Q8 * TRANSISTOR,SI,PNP,SMALL SIG,SE 380394 1
Q9 * HEATSINC ASSY 665445 1
Q10,Q19,Q56 * TRANSISTOR,SI,NPN,SMALL SIGNAL 698225 3
Q12,Q13,Q16,
Q17,Q23,Q24
*
*
TRANSISTOR,SI,N-JFET,HI-VOLTAG 832147
832147
6
Q14,Q15,Q18,
Q20,Q21,Q52, Q53
*
*
*
TRANSISTOR,SI,N-CHAN,TO-92,SWI 832139
832139
832139
7
Q30,Q32 * TRANSISTOR,SI,N-JFET,SOT-23 844584 2
Q31,Q33,Q35 * TRANSISTOR,SI,NPN,SMALL SIGNAL 806463 3
Q34 * TRANSISTOR,SI,PNP,SMALL SIGNAL 838516 1
Q57 * TRANSISTOR,SI,PNP,40V,0.35W,TO-92 698233 1
R1,R28,R33,R39,
R44,R83 R84
*
*
RES,CERM,4.7K,+-5%,.125W,200PPM 740522
740522
7
R2 RES,CF,3K,+-5%,0.25W 810366 1
R3 RES,CF,2K,+-5%,0.25W 441469 1
R6 * RES,CERM,910,+-5%,.125W,200PPM 769257 1
R7 * RES,CERM,620,+-5%,.125W,200PPM 745984 1
R9,R107,R108 * RES,CERM,1.8K,+-5%,.125W,200PPM 746453 3
R10 RES,MF,2.49K,+-1%,0.125W,100PPM 810523 1
R12 * RES,CERM,200,+-5%,.125W,200PPM 746339 1
R13 * RES,CERM,22,+-5%,.125W,200PPM 746230 1
R14 RES,MF,61.9M,+-1%,0.25W,150PPM 851741 1
R15 RES,MF,1.21K,+-1%,0.125W,100PPM 810507 1
R16 * RES,CERM,750,+-5%,.125W,200PPM 746404 1
R19-21,R29,R31,
R41,R48
*
*
RES,CERM,10K,+-5%,.125W,200PPM 746610
746610
10
R22 RES,CF,20K,+-5%,0.25W 697110 1
R23
RESISTOR SMR,RES,CERM,6.8,+-5%,.125W,300PPM,1206
811802 1
R24 * RES,CERM,2.49K,+-1%,.125W,100PPM 806448 1
R25 * RES,CERM,51.1,+-1%,.125W,100PPM 806422 1
R26,R27,R70,R89,
R90
RES,MF,20K,+-0.1%,0.25W,25PPM 810564
810564
5
R30,R50,R85 * RES,CERM,510,+-5%,.125W,200PPM 746388 3
R32 * RES,CERM,10,+-5%,.125W,200PPM 746214 1
R36,R77,R78,
R103,R105
*
*
RES,CERM,1.2K,+-5%,.125W,200PPM 746412
746412
5
R37,R106,R110 * RES,CERM,12,+-5%,.125W,200PPM 845458 3
R38,R49 * RES,CERM,270,+-5%,.125W,200PPM 746354 2
R40 * RES,CERM,100K,+-5%,.125W,200PPM 740548 1
R43,R52,R109 * RES,CERM,3K,+-5%,.125W,200PPM 746511 3
R45 * RES,CERM,2.7K,+-5%,.125W,200PPM 746503 1
R46 * RES,CERM,360,+-5%,.125W,200PPM 783290 1
R47,R60,R62,R66,
R75,R76
*
*
RES,CERM,100,+-5%,.125W,200PPM 746297
746297
6
R51 * RES,CERM,150,+-1%,.125W,100PPM 772780 1
R53,R71 * RES,CERM,5.1K,+-5%,.125W,200PPM 746560 2
R58,R59,R64,
R73,R124-127
*
*
RES,CERM,56K,+-5%,.125W,200PPM 746701
746701
8
R61 RES,CF,1.5K,+-5%,0.25W 810432 1
R63,R65,R95,
R96,R99
*
*
RES,CERM,1K,+-5%,.125W,200PPM 745992
745992
5
R128 RESISTOR SMR,RES,CERM,200K,+-1%,0.1W,100PPM,0805 928882 1
1. Assembly 665448 consists of 369660 and 816587
2. Assembly 665510 consists of part numbers 811760, 129882, 101055, 184044, and 690587
