Fluke 5700A Series User Manual

5700A/5720A Series II Calibrator
Service Manual
6-44
Table 6-12. A11 DAC PCA (cont)
Reference
Designator
Description
Fluke
Stock
No
Tot
Qty Notes
VR13 * ZENER 5243 SMR,ZENER,UNCOMP,13V,5%,9.5MA,0.2W,SOT-
23
642477 1
VR18,VR22 * ZENER 5245 SMR,ZENER,UNCOMP,15V,5%,8.5MA,0.2W,SOT-
23
837187 2
VR25 * ZENER,UNCOMP,3.3V,10%,20.0MA,0.4W 309799 1
VR26 * ZENER,UNCOMP,3.3V,5%,20MA,0.2W 807008 1
VR27 * ZENER,UNCOMP,7.5V,5%,20MA,0.2W 837138 1
VR28 * ZENER,UNCOMP,8.2V,5%,20MA,0.2W 837146 1
VR29 * ZENER,COMP,6.4V,2%,2PPM,1MA 419036 1
VR33,VR34 * ZENER 5236 SMR,ZENER,UNCOMP,7.5V,5%,20MA,0.2W,SOT-
23
837138 2
X1 SOCKET,IC,40 PIN,DUAL WIPE,RETENTION 756668 1
XU22 CONNECTOR, ADAPTER, SO8, 8-PIN 1778899 1
Z2 * RNET,MF,POLY,SIP,5700 LO V DIVIDER 890244 1
Z4 RES,CERM,SIP,10 PIN,5 RES,56K,+-2% 529131 1
Z5 RES,CERM,SIP,6 PIN,5 RES,510,+-2% 459974 1
Z8 * RNET,MF,HERM,SIP,5700 LO V INST AMP 809418 1
Z10 RNET,MF,HERM,SIP,5700 A TO D CONV 833830 1
Z12 RES,CERM,SIP,6 PIN,5 RES,10K,+-2% 500876 1

Fluke 5700A Series Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% non-condensing
Frequency Range	10 Hz to 1 MHz
Accuracy	Varies by function and range. See manufacturer's specifications for details.
Output Stability	Varies by function and range. See manufacturer's specifications for details.
Power Requirements	50 Hz to 60 Hz
