Fluke 5700A Series User Manual

5700A/5720A Series II Calibrator
Service Manual
6-46
Table 6-13. A11A1 DAC Filter SIP PCA
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
C1-6 CAP,POLYES,0.33UF,+-20%,50V 853903 6
C10,C11 CAP,POLYPR,1UF,+-5%,50V,HERMETIC 783811 2
C12,C13 CAP,CER,0.22UF,+80-20%,50V,Y5V,1206 740597 2
C14 CAP,CER,100PF,+-10%,50V,C0G,1206 740571 1
P21,P22 HEADER,2 ROW,.100CTR,RT ANG,6 PIN 912217 2
R1,R2 * RES,CERM,11K,+-5%,.125W,250PPM 769752 2
R3,R5 * RES,CERM,18K,+-5%,.125W,200PPM 746636 2
R4 * RES,CERM,22K,+-5%,.125W,200PPM 746651 1
U1 * IC,OP AMP,ULTRA-LOW-NOISE,SOIC 783001 1
U2 * IC,OP AMP,PRECISION,LOW NOISE 782920 1
VR1 * ZENER,UNCOMP,15.0V,5%,8.5MA,0.4W 266601 1

Fluke 5700A Series Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% non-condensing
Frequency Range	10 Hz to 1 MHz
Accuracy	Varies by function and range. See manufacturer's specifications for details.
Output Stability	Varies by function and range. See manufacturer's specifications for details.
Power Requirements	50 Hz to 60 Hz
