5700A/5720A Series II Calibrator
Service Manual
6-58
Table 6-17. A13A1 Oscillator Wideband SMD PCA
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
C1,C3,C4,C6-8,
C12,C13
CAP,CER,0.22UF,+80-20%,50V,Y5V 740597
740597
8
C2 CAP,CER,100PF,+-10%,50V,C0G,1206 740571 1
C5 CAP,CER,10PF,+-10%,100V,C0G,1206 806943 1
C9 CAP,CER,470PF,+-10%,50V,C0G,1206 747360 1
C10 CAP,CER,1000PF,+-10%,50V,C0G,1206 747378 1
C11 CAP,CER,0.01UF,+-10%,50V,X7R,1206 747261 1
CR4-6,CR9,C10 * DIODE,SI,BV=70V,IO=50MA,DUAL,SOT-23 742320 5
P1,P2 HEADER,2 ROW,.100CTR,RT ANG,1206 806935 2
Q1 * TRANSISTOR,SI,N-JFET,SOT-23 844584 1
Q2,Q4,Q5 * TRANSISTOR,SI,NPN,SMALL SIGNAL 845438 4
Q3 * TRANSISTOR,SI,PNP,SMALL SIGNAL 742684 1
Q6,Q8 * TRANSISTOR,SI,PNP,SMALL SIGNAL 838516 2
Q9 * TRANSISTOR,SI,NPN,SMALL SIGNAL 742676 1
R1,R9 * RES,CERM,2K,+-5%,.125W,200PPM 746461 2
R2 * RES,CERM,2.7K,+-5%,.125W,200PPM 746503 1
R3 RES,CERM,453,+-5%,.125W,200PPM 801415 1
R4,R26 * RES,CERM,510,+-5%,.125W,200PPM 746388 2
R5 * RES,CERM,5.1K,+-5%,.125W,200PPM 746560 1
R6,R23,R31 * RES,CERM,3.9K,+-5%,.125W,200PPM 746545 3
R7,R16,R18,R19,
R21 R27-29
*
*
RES,CERM,47,+-5%,.125W,200PPM 746263
746263
8
R8 * RES,CERM,100K,+-5%,.125W,200PPM 740548 1
R10 * RES,CERM,56,+-5%,.125W,200PPM 807727 1
R11,R17 * RES,CERM,150,+-1%,.125W,100PPM 772780 2
R12 * RES,CERM,27,+-5%,.125W,200PPM 807735 1
R13 * RES,CERM,100,+-5%,.125W,200PPM 746297 1
R14 * RES,CERM,750,+-5%,.125W,200PPM 746404 1
R15 * RES,CERM,15K,+-5%,.125W,200PPM 746628 1
R20 * RES,CERM,390,+-5%,.125W,200PPM 740498 1
R22 * RES,CERM,330,+-5%,.125W,200PPM 746370 1
R24 * RES,CERM,910,+-5%,.125W,200PPM 769257 1
R25 * RES,CERM,1.8K,+-5%,.125W,200PPM 746453 1 1
R30 RES,VAR,CERM,1K,+-10%,0.5W 912360 1
U1 * IC,OP AMP,ULTRA-LOW-NOISE,SOIC 783001 1
U2 * IC,OP AMP,SINGLE,LOW NOISE FAST,SOIC 783720 1
VR1,VR5-7 * ZENER,UNCOMP,6.2V,5%,20MA,0.2W 782441 4
VR2 * ZENER,UNCOMP,22V,5%,5.6MA,0.2W 831230 1
VR3,VR4 * ZENER,UNCOMP,3.3V,5%,20MA,0.2W 807008 2
1. R25 is selected at test as one of the following: 1.8k (746453), 2K (746461), or 2.2K.
