Fluke 5700A Series User Manual

List of Replaceable Parts
Parts List
6
6-63
Table 6-19. A15 High Voltage/High Current PCA
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
C2,C29,C42 CAP,POLYES,0.01UF,+-10%,50V 715037 3
C4 CAP,POLYPR,0.022UF,+-5%,1500V 806968 1
C5,C15-17,C20,
C21 C23-28,C32
C33,C35,C38,C40
CAP,POLYES,0.1UF,+-10%,50V 649913
649913
649913
17
C6 CAP,POLYES,0.047UF,+-10%,50V 820548 1
C7 CAP,CER,180PF,+-2%,50V,C0G 820522 1
C8 CAP,CER,680PF,+-5%,50V,C0G 743351 1
C10 CAP,CER,82PF,+-2%,50V,C0G 714857 1
C11 CAP,CER,47PF,+-20%,50V,C0G 706705 1
C12,C13,C43 CAP,POLYES,0.47UF,+-10%,50V 697409 3
C14,C19 CAP,TA,2.2UF,+-10%,35V 697433 2
C18 CAP,CER,100PF,+-5%,50V,C0G 831495 1
C22 CAP,POLYES,0.01UF,+-10%,50V 715037 1
C30,C31,C37,C39 CAP,TA,10UF,+-20%,35V 816512 4
C34 CAP,TA,22UF,+-20%,10V 658971 1
C41 CAP,POLYES,0.22UF,+-10%,50V 706028 1
CR1,CR4 CR11-
16,CR24,CR25
*
*
DIODE,SI,BV=75V,IO=150MA,500MW 203323
203323
10
CR2,CR17,CR18,
CR20,CR21
*
*
DIODE,SI,N-JFET,CURRENT REG,IF 852116
852116
5
CR5,CR6,CR9,
CR10 CR22,
CR23
DIODE,SI,1KV,1 AMP 707075 6
CR19 * DIODE,SI,N-JFET,CURRENT REG,IF 852124 1
H1,H2 SCREW,PH,P,LOCK,SS,6-32,.500 320051 2 1
H4 * HYBRID ASSEMBLY, TESTED 813444 1
H6-10,H21 SCREW,PH,P,LOCK,STL,6-32,.250 152140 6
H17-20 RIVET,S-TUB,OVAL,AL,.087,.343 838458 4
HR7 * HIGH VOLTAGE DC HYBRID 775254 1
K1 RELAY,ARMATURE,4 FORM C,5V,LATCH 715078 1
K2,K3 RELAY,ARMATURE,2 FORM C,5V,LATCH 769307 2
K4,K5,K8,K9,K12 RELAY,ARMATURE,2 FORM C,5V 733063 5
K6,K7,K10,K11,
K14
RELAY,ARMATURE,1 FORM A/1 FORM 831545
831545
5
L4,L5 CHOKE,6TURN 320911 2
MP1,MP2 EJECTOR,PWB,NYLON 494724 2
MP3 SHIELD, HIGH VOLTAGE, REAR 791921 1
MP4 MOLDED COVER, REF. HYBRID 797746 1
MP5 MOLDED COVER, HYBRID, R-NET 775619 1
MP6-9 SPACER,BROACH,SNAP,BR,1.062 832469 4
MP10 THERMAL INSULATOR, HIGH VOLTAG 797829 1 1
MP11,MP12 INSUL PT,TRANSISTOR MOUNT,DAP,T0-5 152207 2
MP14-16 CABLE TIE,5",1.375"DIA 807230 3
MP22 HI VOLT CLAMP BAR 760850 1 1
P601,P602 CONN,DIN41612,TYPE C,RT ANG,64 PIN 807800 2
Q3,Q13 * TRANSISTOR,SI,NPN,SMALL SIGNAL 346916 2
Q4,Q15,Q22,Q23 * TRANSISTOR,SI,NPN,SMALL SIGNAL 698225 4
Q6,Q12 * TRANSISTOR,SI,PNP,SMALL SIGNAL 402586 2
Q8,Q18 * TRANSISTOR,SI,BV=40V,40W,TO-220 369660 2
Q9,Q19 * TRANSISTOR,SI,BV=60V,65W,TO-220 386128 2
Q10 * TRANSISTOR,SI,P-JFET,TO-92 852111 1
Q11 * TRANSISTOR,SI,BV=100V,50W,TO-220 454041 1 1
Q14 * TRANSISTOR,SI,BV=100V,40W,TO-220 454033 1 1
Q16,Q24 * TRANSISTOR,SI,PNP,40V,0.35W,TO-92 698233 2
Q20,Q21 * TRANSISTOR,SI,N-JFET,SEL,TO-92 707703 2
