5700A/5720A Series II Calibrator
Service Manual
6-70
Table 6-21. A16A1 Power Amplifier Digital Control SIP PCA
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
C52 CAP,AL,15UF,+-20%,35V 614024 1
C53,C56 CAP,CER,33PF,+-5%,50V,C0G 714543 2
C54 CAP,CER,470PF,+-10%,50V,C0G 733071 1
C55,C57 CAP,POLYES,0.22UF,+-5%,50V 747519 2
L4 CHOKE,6TURN 320911 1
MP3 HEADER,2 ROW,.100CTR,RT ANG,10 PIN 658112 1
P1,P2 HEADER,2 ROW,.100CTR,RT ANG,26 PIN 512590 2
R2,R106 RES,CF,1K,+-5%,0.25W 780585 2
R101,R105 RES,MF,1K,+-1%,0.125W,100PPM 816595 2
R102 RES,CF,16K,+-5%,0.25W 714303 1
R103 RES,CF,10K,+-5%,0.25W 697102 1
R104 RES,CF,4.7K,+-5%,0.25W 721571 1
U9 * IC,LSTTL,3-8 LINE DCDR W/ENABL 407585 1
U10,U12 * IC,BIMOS,8 CHNL HI-VOLT DRVR W/LATCH 782912 2
U11 * IC,CMOS,PROGRMBL PERIPHERAL INTERFACE 780650 1
U13,U15 * IC,COMPARATOR,QUAD,14 PIN DIP 387233 2
U14 * IC,CMOS,8-1 LINE MUX/DEMUX ANALOG,SW 836304 1
Z1 RES,CERM,SIP,10 PIN,9 RES,47K,+-2% 485193 1
Z2 RES,CERM,SIP,10 PIN,9 RES,4.7K,+-2% 484063 1
