Fluke 5700A Series User Manual

5700A/5720A Series II Calibrator
Service Manual
6-82
Table 6-25. A20 CPU PCA
Ref Des Description
Part
Number
Qty Note
C1 CAPACITOR SMR,CAP,TA,220UF,+-20%,10V,7343H 106021 1
C2-4,C6-7
C14-16 C18,
C101-111,
C113, C115,
C116, C119-
120, C125-
133, C142-
143, C152
CAPACITOR SMR,CAP,CER,0.1UF,+-10%,50V,X7R,0805 690500 37
C5 CAPACITOR SMR,CAP,TA,15UF,+-20%,35V,7343 690252 1
C8-11 CAPACITOR SMR,CAP,CER,22PF,+-1%,50V,C0G,0805 867663 4
C12-13, C80 CAPACITOR SMR,CAP,CER,0.22UF,+-10%,25V,X7R,1206 106625 3
C17 CAPACITOR SMR,CAP,TA,47UF,+-20%,16V,7343 644994 1
C81 CAPACITOR SMR,CAP,CER,330PF,+-5%,50V,C0G,0805 512038 1
C82 CAPACITOR SMR,CAP,CER,150PF,+-5%,50V,C0G,0805 866533 1
C100 CAPACITOR SMR,CAP,TA,2.2UF,+-20%,20V,3528 854760 1
CR2-3, CR7 DIODE,GF1B SMR,DIODE,SI,100V,1A,DO-214 912451 3
CR4-6, CR8 DIODE,BAT54A SMR,DIODE,SI,SCHOTT,DUAL,30V,200MA,SOT-23 942594 4
DS1 LED,RED,BR1101W,1.6 MCD,20MA,1.7V,1206,TAPE 804788 1
H3-6 RIVET,AL,.089 DIA,.344 L,SEMI-TUBULAR,OVAL HEAD 838458 4
L80-81 INDUCTOR SMR,INDUCTOR,10UH,+-10%,.015ADC 105965 2
MP1 5700A-3006,A-20, MAIN CPU, PCB 1591062 1
P61-62 CONNECTOR ,CONN,DIN41612,TYPE C,RT ANG,64 PIN 802402 2
R1, R3 RESISTOR SMR,RES,CERM,470,+-5%,.125W,200PPM,1206 740506 2
R2, R7 RESISTOR SMR,RES,CERM,0,+.05 MAX,.125W,1206 810747 2
R4 RESISTOR SMR,RES,CERM,10M,+-5%,.125W,400PPM,1206 783274 1
R5 RESISTOR SMR,RES,CERM,1.8K,+-5%,.125W,200PPM,1206 746453 1
R6 RESISTOR SMR,RES,CERM,6.2K,+-5%,.125W,200PPM,1206 746016 1
R8-9 RESISTOR SMR,RES,CERM,75,+-5%,.125W,200PPM,1206 811323 2
R10-16 RESISTOR SMR,RES,CERM,10K,+-1%,.125W,100PPM,1206 769794 7
R51-54 RESISTOR SMR,RES,CERM,5.11K,+-1%,.125W,100PPM,1206 810663 4
R56, R17 RESISTOR SMR,RES,CERM,1K,+-1%,.125W,100PPM,1206 783241 2
R58-59 RESISTOR,CERMET,39.2K,+-1%,0.1W,100PPM,0805,TAPE 943092 2
R60-61 RESISTOR SMR,RES,CERM,1M,+-1%,.125W,100PPM,1206 836387 2
SW1 SWITCH, MICRO, PUSHBUTTON, SPST, MOMENTARY, 24VDC@30MA, SMT,
TAPE
1589043 1
T1 TRANSFORMER,SIGNAL,1:1,0.3-150MHZ,1515,TAPE 690669 1
TP1, TP3-14 CONNECTOR,TERMINAL,TEST POINT,1510,TAPE 602125 13
U1 BPLR TL7705A SMR,IC,VOLT SUPERVISOR,5V SENSE,SOIC 780502 1
U2 IC, LOGIC, 74AC05, 2.0V-6.0V, HEX INVERTER W/OPEN DRAIN OUTPUTS,
SOIC14, TAPE
1589152 1
U3 CMOS 74HCU04 SMR,IC,CMOS,HEX INVERTER,UNBUFFERED,SOIC 806893 1
U4, U11 IC, LOGIC, 74HC4020, 2.0V-6.0V, 14-STAGE BINARY COUNTER, CLR, SOIC16,
TAPE
1589004 2
U5 IC, PLD, ATF22V10C, 5.0V, 500-GATE, EE, PROGRAMMED, U5, SOICW24,
TAPE
1609625 1
U6 IC, PLD, ATF22V10C, 5.0V, 500-GATE, EE, PROGRAMMED, U6, SOICW24,
TAPE
1609633 1
U8 IC,MICROPROCESSOR,MC68HC000,16 BIT,5V,10 MHZ,PLCC68,TAPE 866777 1
U9 CMOS 74HC32 SMR,IC,CMOS,QUAD 2 INPUT OR GATE,SOIC 783712 1
U10 IC, PLD, ATF22V10C, 5.0V, 500-GATE, EE, PROGRAMMED, U10, SOICW24,
TAPE
1609640 1
U13 IC,MEMORY,EEPROM,28C256,256KB,32KX8,5V,250NS,HIGH
ENDURANCE,PLCC32,TAPE
1588978 1
U15 IC,MEMORY,FLASH,28F800,8MB,512KX16,5V,80NS,BOTTOM
BOOT,PROGRAMMED,SO44,TAPE
See Note 1 1

Fluke 5700A Series Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% non-condensing
Frequency Range	10 Hz to 1 MHz
Accuracy	Varies by function and range. See manufacturer's specifications for details.
Output Stability	Varies by function and range. See manufacturer's specifications for details.
Power Requirements	50 Hz to 60 Hz
