Fluke 5700A Series User Manual

5700A/5720A Series II Calibrator
Service Manual
6-86
Table 6-27. A21 Rear Panel PCA (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
U13 * IC,OP AMP,OPA132 1779200 1
U14 * IC,CMOS,PROGRMBL PERIPHERAL INTERFACE 780650 1
U16,U17 * IC,BIMOS,8 CHNL HI-VOLT DRVR W/LATCH 782912 2
U18 * IC,COMPARATOR,HI-SPEED,14 PIN 647115 1
VR1,VR2 * ZENER,UNCOMP,3.3V,10%,20.0MA,0.4W 309799 2
VR3 * ZENER,UNCOMP,4.7V,10%,20.0MA,0.4W 387084 1
W1 CABLE, BOOST, B-OUT HIGH 802827 1
W2 CABLE, BOOST, B-SENSE HIGH 802850 1
W3 CABLE, BOOST HIGH VOLTAGE 802843 1
X8 SOCKET,IC,24 PIN 812198 1
XU13 CONNECTOR, ADAPTER, SO8,8-PIN 1778899 1
Z1,Z2 RES,CERM,SIP,10 PIN,9 RES,4.7K,+-2% 484063 2
Z4 RES,CERM,SIP,6 PIN,5 RES,4.7K,+-2% 494690 1
Z5 RES,CERM,SIP,6 PIN,5 RES,10K,+-2% 500876 1

Fluke 5700A Series Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% non-condensing
Frequency Range	10 Hz to 1 MHz
Accuracy	Varies by function and range. See manufacturer's specifications for details.
Output Stability	Varies by function and range. See manufacturer's specifications for details.
Power Requirements	50 Hz to 60 Hz
