Fluke 8062A - Page 100

8062A
Instruction Manual
5-10
Table 5-2. A1 Main PCB Assembly (cont)
Ref.
Des
Description PN Qty Notes
MP12-15 SPACER,LED .330 LG 930342 4
Q1 * TRANSISTOR,SI,N-JFET,SEL,TO-92 721936 1
Q3,Q4,Q6 * TRANSISTOR,SI,NPN,60V,310MW,SEL,TO-92 886916 3
Q5 * TRANSISTOR,SI,NPN,30V,1W,TO-92 242065 1
R1,R2 RES,MF,1K,+-1%,100PPM,FLMPRF,FUSIBLE 474080 2 1
R3 RES,CC,100M,+-10%,0.5W 190520 1
R4 RES,CF,5.6K,+-5%,0.25W 442350 1
R5 RES,VAR,CERM,2K,+-20%,0.3W 603753 1
R6 RES,VAR,CERM,200,+-20%,0.3W 603738 1
R7 RES,MF,154K,+-1%,0.125W,100PPM,1206 289447 1
R8 RES,VAR,CERM,1K,+-20%,0.3W 614065 1
R10 RES,MF,3.65K,+-1%,0.25W,100PPM 810754 1
R15 RES,VAR,CERM,3K,+-20%,0.3W 689627 1
R16 RES,MF,383K,+-1%,0.125W,100PPM 288498 1
R18 RES,VAR,CERM,100,+-20%,0.3W 614057 1
R20 RES,CC,220K,+-10%,1W 109652 1
R22 RES JUMPER,0.02,0.25W 682575 1
R31 RES,CF,10,+-5%,0.25W 807669 1
R32 RES,CC,100K,+-5%,1W 641282 1
R34,R35 RES,CF,12,+-5%,0.25W 442178 2
R36 RES,CF,51K,+-5%,0.25W 376434 1
R37 RES,CF,68K,+-5%,0.25W 376632 1
RJ1-4 VARISTOR,430V,+-10%,1.0MA 447672 4
RT1 THERMISTOR,RECT.,POS.,1K,+-40% 446849 1
S1 SWITCH ASSY 535021 1
S9 SWITCH,SLIDE,SPDT,PWB,RA 453365 1
U1 DIODE BRIDGE,SI,50V,1A,DIP 418582 1
U4 * IC,VOLTAGE CONVERTER,10.5 V MA 586248 1
VR1 ZENER,UNCOMP,6.2V,5%,20.0MA,0.4W 325811 1
VR2 * IC, 1.22V,50 PPM T.C.,BANDGAP 508259 1
VR3 ZENER,UNCOMP,12.0V,10%,10.5MA,0.4W 741074 1
W1 WIRE,NONINSUL,JUMPER,.150CTR 643452 1
XU3 SOCKET,IC,40 PIN,DUAL WIPE,RETENTION 756668 1
