Fluke 8062A - Page 99

List of Replaceable Parts
5
5-9
Table 5-2. A1 Main PCB Assembly
Ref.
Des
Description PN Qty Notes
A3 * RMS PCB ASSEMBLY 609120 1
C1,C023,
C32,C34
CAP,AL,100UF,+-20%,6.3V,SOLV PROOF 615906 4
C2 CAP,CER,8PF,+-0.25PF,1000V,C0H 643551 1
C3 CAP,VAR,0.25-1.5PF,1700V,TEFLON 218206 1
C4 CAP,CER,47PF,+-2%,100V,C0G 832295 1
C5 CAP,CER,0.01UF,+-2%,50V,C0G 631044 1
C6 CAP,CER,820PF,+-2%,50V,C0G 631002 1
C7 CAP,VAR,3-11PF,100V,CER 641712 1
C9,C18 CAP,POLYPR,0.22UF,+-10%,160V 446799 2
C10,C14 CAP,CER,0.01UF,+-20%,50V,Z5U 659045 2
C11,C15 CAP,CER,0.22UF,+-20%,50V,Z5U 831982 2
C12,C21 CAP,AL,10UF,+-20%,16V,SOLV PROOF 602326 2
C13,C30,
C37
CAP,CER,0.01UF,+-20%,50V,X7R 816249 3
C16 CAP,TA,1UF,+-20%,35V 161919 1
C17 CAP,POLYES,0.01UF,+-10%,1000V 822361 1
C22 CAP,POLYPR,0.1UF,+-10%,160V 446781 1
C29 CAP,CER,68PF,+-2%,100V,C0G 362756 1
C36 CAP,AL,22UF,+-20%,16V,SOLV PROOF 614750 1
CR1 * I-REG DIODE,1MA,10%,SEL,TO-226 334839 1
CR2 DIODE,SI,100V,1A,DO-41 698555 1
CR3,CR4 * DIODE,SI,75V,150MA,DO-35 659516 2
J1-3 RECEPTACLE 508606 3
J4 ACK,PWB,RT ANG 423897 1
J5 CONTACT ASSY TERMINATION 651653 1
J6-8,
J10-14
PIN,SINGLE,PWB,0.025 SQ 603910 8
LS1 AF TRANSD,PIEZO,22MM,400UW,4KHZ 602490 1
MP1 FUSE CASE 540716 1
MP2 FUSE CLIP 534925 1
MP3 FUSE CLIP 535203 1
MP5 SPACER,SWAGE,.250 RND,BR,6-32,.687 544254 1
MP6 SPRING 535211 1
